| Performance | rated load | 7500kg | |
| overall weight | 23000kg | ||
| rated bucket capacity | 4.5m³ | ||
| maximum tractive force | 200KN | ||
| maximum breakout force | 210KN | ||
| maximum grade ability | 30° | ||
| maximum dump height | 3525mm | ||
| maximum dump reach | 1290mm | ||
| overall dimension(LXWXH) | 9500x3250x3400mm | ||
| minimum turning radius | 6600mm | ||
| Engine | model | Weichai Steyr WP10G286E301 | Cummins Steyr QSL8.9 |
| type | In-line\water cooling\Electric controlled\high-pressure common rail | ||
| No. of cylinder-bore/stroke | 6-126x130mm | 6-114x145mm | |
| rated power | 210kw-2200r/min | 209kw-2200r/min | |
| maximum torque | 1185N.m | 1250N.m | |
| min fuel-consume ratio | / | ≤201g/kw.h | |
| Transmission system | torque converter | ZF230 | |
| gearboxmode | Automated MechanicalTransmission | ||
| gear shift | 4 forward shift 3 reverse shift | ||
| maximum speed | 40km/h | ||
| Drive axles | main reducing spiral | bevelgear grade lreduction | |
| decelerating mode | planetary reduction, grade 1 | ||
| wheel base | 3500mm | ||
| wheel tread | 2400mm | ||
| minimumground clearance | 450mm | ||
| Hydraulic system | system working pressure | 24MPa | |
| boom lifting time | 6±0.25s | ||
| total time | 10±0.5s | ||
| fuel tank capacity | 180L | ||
| function of leveling automatically | yes | ||
| Brake system | service brake | air over hydraulic disc brake on 4 wheels | |
| parking brake | manual parking brake | ||
| Tyre | specificatior | 750/65R25 | |
| front tyre pressure | 0.65Mpa | ||
| rear tyre pressure | 0.55Mpa | ||
