2.54mm Pin Header Single Row SMT Type

2 month ago

4 0

HuiZhou Antenk Electronics Co., LTD

 5 year year

Product details

This 2.54mm Single Row SMT Type Pin Header developed and manufactured by Antenk Electronics serves as a reliable line to board connection component for surface mount circuit assembly. With a fixed 2.54mm pin pitch and customizable pin counts ranging from 1 to 40 positions, the product offers two structural versions Type A and Type B, alongside multiple optional pin lengths and plastic body heights to match diverse PCB layout demands. Constructed with brass contacts and PA6T black insulation material meeting UL94 V 0 flammability standard, this pin header supports various plating options including selective gold flash, different thickness gold plating and tin plating to balance electrical conductivity and anti corrosion performance. It is rated for 3 Amp working current, with minimum 1000MΩ insulation resistance, maximum 20MΩ contact resistance and AC500V dielectric withstanding voltage, capable of stable operation within minus 65 degree Celsius to plus 125 degree Celsius. Users install the connector via standard SMT reflow soldering according to official PCB layout drawings to realize stable circuit connection. Operators must strictly control reflow oven temperature curve to avoid plastic deformation, and store unused connectors in dry sealed packaging to prevent pin oxidation and surface contamination.

All pin headers are produced under standardized full process workflow at Antenk Electronics covering precision mold design, brass terminal high speed stamping, high temperature resistant plastic injection molding, surface electroplating, automatic assembly and professional laboratory performance inspection. Established in 2007, our company operates two production bases covering over 10000 square meters with more than 250 skilled staff. Equipped with imported precision stamping machines, plastic injection equipment and complete testing instruments, we own hundreds of self developed connector molds and automated production devices. Different from small sized manufacturers, Antenk holds independent import and export rights, can issue 13 percent VAT invoices, and has obtained UL certification, ISO9001, ISO14001 and IATF16949 automotive quality system certification. Our self owned brand ANTENK is recognized as Guangdong Famous Trademark, all products comply with EU RoHS and REACH environmental regulations, and over 70 percent of our connectors are exported globally. We provide flexible customized solutions on pin number, plating type, packaging mode and housing material to meet personalized client requirements that most ordinary factories cannot support.

This SMT pin header is widely applied in liquid crystal display devices, digital cameras, communication equipment, industrial control modules, digital household appliances, electronic toys, computer peripherals, automotive electronics and precision testing instruments. Our products are well received across major domestic electronic cities and dozens of overseas regions including Europe, Southeast Asia and South America. Supported by experienced engineering and quality management teams, every production batch undergoes strict electrical, temperature and mechanical performance tests before delivery to guarantee long term stable connection under harsh working conditions. Antenk supplies diversified packaging options including tray bag tape and reel to fit automated customer production lines, delivering one stop customized connector solutions for global electronic manufacturers with stable quality, flexible service and competitive comprehensive advantages.
