●SIL2, PL d, Type 3, TÜV Rheinland certified, compliant with standards IEC 61508, ISO 13849, and IEC 61496；
● The measurement accuracy is not affected by the change of target reflectivity. Stable and consistent measurement result in any complex application scenarios and among several lidars.；
● Support static and dynamic input free transformation and 64 protection zone settings, which can be combined freely to adapt to complex and variable application scenarios；
● The window adopts a stepped structure design to achieve super dirt resistance performance, which greatly reduces the number of maintenance。
Work pattern
Through the upper computer software, the detection area of the radar can be set to the PAA mode (protection zone+alarm 1+alarm zone 2) or PP mode (protection zone 1+protectionZone 2) to meet different forms of protection needs.
In PAA or PP mode, KLMs can set up to 64 area groups with different shapes. Users can assign different area groups to different Monitoring Cases based on their needs, and configure the conditions for implementing the protection of the area group. When the conditions are met, they will automatically switch to the corresponding area group.
The conditions for achieving region group switching include static control input, dynamic control input, and contour recognition input. The three conditions can be configured individually or in combination as conditions for activation of an area group.
If you are interested in the product, contact 2bvideo.com for more information for more information
