2.00mm Box Header 180° H

5 week ago

4 0

HuiZhou Antenk Electronics Co., LTD

 5 year year

Product details

Produced by Huizhou Antenk Electronics Co., Ltd, the BHCS01 series 2.00mm 180-degree box header with 5.75mm overall height serves as a reliable connection component to deliver stable signal transmission and safe power conduction between printed circuit boards for compact electronic equipment. This product series covers contact specifications ranging from 06 pins to 68 pins, adopting brass as conductive contact material, with diversified surface treatment options including gold flash, selective gold plating and tin over nickel plating. The insulating housing is manufactured from PA6T filled with 30 percent glass fiber, which meets UL94V 0 flame retardant safety standard. It is rated for 2.0 Amp nominal current, equipped with minimum 1000MΩ insulation resistance and maximum 20MΩ contact resistance, and can withstand 500V alternating and direct voltage, operating stably within the temperature range of minus 40 degrees Celsius to 105 degrees Celsius. Our complete manufacturing workflow consists of independent mold design and development, precision terminal stamping, high temperature resistant plastic injection molding, surface anti-corrosion plating, automatic assembly and comprehensive electrical performance testing in professional laboratories. Supported by Taiwan high-speed punching machines and Japanese precision injection molding equipment, we strictly control PCB layout dimensional tolerances and supply three housing color options including black, blue and white to facilitate product differentiation and assembly identification.

This 180-degree box header adopts traditional through-hole DIP soldering installation method, compatible with both automated wave soldering and manual welding operations for PCB assembly. It is widely deployed in industrial control equipment, communication modules, automotive electronic components, smart home appliances, precision measuring instruments, computer peripheral devices and consumer electronic products. During practical application, users must abide by the official recommended PCB layout parameters for soldering installation, avoid excessive welding temperature and heating duration to prevent deformation of the insulating housing, and keep contact terminals away from dust, moisture and corrosive substances to extend the service life of connectors. All products comply with EU RoHS and REACH environmental directives, most specifications are certified by UL with certificate number E472792, and our factory has obtained ISO9001, ISO14001 and IATF16949 quality management system certifications, with multiple packaging solutions such as tray, bag, tube and tape reel to satisfy various logistics and production demands.

Compared with other connector manufacturers, Antenk owns more than 250 sets of self-developed plastic molds and 180 sets of precision metal terminal molds, enabling flexible customization on pin count, plating type, insulating material, housing color and packaging mode for this box header series. Our 10000 square meter production base located in Guangdong Province has 250 experienced staff, over 180 automatic assembly machines and 20 sets of professional testing devices, which guarantees stable product consistency and large order delivery capability. As a certified Guangdong Famous Trademark enterprise, more than 70 percent of our connectors are exported to global markets. Our strict multi-stage quality inspection system delivers outstanding structural stability and reliable anti-interference performance, effectively lowering circuit failure rates and establishing long-term cooperative trust with global customers across Europe, America, Southeast Asia and other international regions.
