2.50mm Pitch SMT Wafer Connector Series

2 month ago

6 0

HuiZhou Antenk Electronics Co., LTD

 5 year year

Product details

Manufactured by Huizhou Antenk Electronics Co., Ltd, the AW2508M series 2.50mm pitch SMT wafer connector is designed to achieve compact and reliable electrical interconnection for miniature electronic PCB assemblies, delivering stable power transmission and anti-interference signal transmission. This product covers specifications from 2 pins to 15 pins, with brass contacts finished with tin plating, while the housing and protective cover adopt high performance PA9T material complying with UL94V 0 flame retardant standard in natural color. It features a rated current of 3A and rated voltage of 100V AC DC, with 1000MΩ minimum insulation resistance and 800V AC DC dielectric withstand voltage, the contact resistance is controlled within 15 milliohms after environmental tests, and it works steadily between minus 25 degrees Celsius and 85 degrees Celsius. The complete manufacturing process includes independent mold design, precision terminal stamping, high temperature resistant plastic injection molding, surface anti corrosion plating, automated assembly and strict electrical reliability testing in our professional laboratory. Equipped with imported Taiwan high speed punching and Japanese precision injection molding equipment, this connector supports even and odd pin layouts with pin 1 polarity marking, and strictly complies with standardized PCB layout tolerance to guarantee stable SMT patch soldering quality.

This SMT wafer connector adopts surface mount patch installation compatible with automatic reflow soldering processes, supplied on tape and reel packaging with 500 pieces per reel for high volume automated production. It is widely applied in industrial control modules, automotive electronic accessories, communication devices, smart home appliances, precision measuring instruments, digital storage equipment and consumer electronic products. During application, users must follow the official PCB layout parameters for patch placement, avoid excessive high temperature and long heating time in reflow soldering to prevent plastic housing deformation, and keep contact areas away from dust, moisture and corrosive substances to extend service life. All products comply with EU RoHS and REACH environmental standards, most items obtain UL certification numbered E472792, and our factory holds ISO9001, ISO14001 and IATF16949 quality management certifications to ensure consistent safety and environmental performance.

Compared with other connector manufacturers, Antenk owns more than 250 sets of self developed plastic molds and 180 sets of precision metal terminal molds, enabling flexible customization on pin number, structural layout and packaging mode for this SMT wafer series. Our 10000 square meter production base with 250 professional staff is equipped with over 180 automatic assembly machines and 20 sets of professional testing instruments, ensuring stable product consistency and large batch delivery capacity. As an enterprise certified with Guangdong Famous Trademark qualification, more than 70 percent of our connectors are exported globally. Our multi stage incoming, in process and finished product inspection system delivers outstanding high temperature resistance and reliable mating performance, effectively reducing soldering failure risks and building long term trusted cooperation with customers across Europe, America, Southeast Asia and other international regions.
