Premium CR2032 Coin Cell Holder with Secure Fit

4 week ago

1 0

HuiZhou Antenk Electronics Co., LTD

 5 year year

Product details

Manufactured by Huizhou Antenk Electronics Co., Ltd, this dedicated CR2032 coin cell holder is a professional PCB power component designed to fix CR2032 button batteries and supply stable backup power for electronic circuits. According to drawing specifications, the outer housing is molded from durable PBT material, while internal elastic contact pieces are made of brass. Multiple surface plating choices are available including tin plating, gold flash and several grades of selective gold plating to meet different anti-oxidation and conductive demands. Its electrical indicators feature maximum 30 milliohms contact resistance, minimum 1000 megaohms insulation resistance and 500V AC dielectric withstand voltage for one second. The product maintains stable working performance within the temperature range from minus 25 degrees Celsius to 85 degrees Celsius. Standard PCB footprint is preset with fixed hole positions to fit automatic SMT reflow soldering. Our complete production workflow includes independent precision mold development, high-speed brass terminal stamping, PBT plastic injection molding, surface electroplating and automatic assembly. Imported stamping and injection molding equipment ensures consistent dimensional accuracy and structural elasticity for long-term battery clamping.

This CR2032 coin cell holder provides tray packing and tape reel packing two mainstream packaging options to suit manual mounting and fully automatic SMT production lines. Operators align the two soldering pins with corresponding pads on printed circuit boards following the official PCB layout diagram and complete reflow soldering, then insert a standard CR2032 coin battery into the cavity with correct positive and negative polarity to finish power connection. It is widely applied in industrial control memory backup modules, smart remote controllers, wearable electronic gadgets, portable testing meters, digital equipment and household intelligent sensor devices. During usage, users must strictly avoid reversed battery installation to prevent short circuit damage, control reflow temperature properly to prevent PBT housing deformation, and store unused holders in dry environment to avoid brass contact rusting. All products comply with EU RoHS and REACH environmental standards, most specifications obtain UL certification numbered E472792, and our factory has passed ISO9001, ISO14001 and IATF16949 automotive quality management certifications.

Compared with other connector manufacturers, Antenk owns more than 250 sets of self-developed plastic molds and 180 sets of precision brass stamping molds, supporting customized contact plating types and packaging methods for this CR2032 battery holder series. Our 10000-square-meter manufacturing base with 250 professional employees is equipped with over 180 automatic assembly machines and 20 sets of professional testing instruments, guaranteeing stable batch quality and fast delivery for bulk orders. As a Guangdong Famous Trademark certified enterprise, more than 70 percent of our battery holders are exported to global markets. Our multi-stage incoming, in-process and finished product inspection system optimizes the elastic clamping structure, effectively preventing poor power contact caused by battery loosening and establishing long-term trusted cooperative partnerships with customers across Europe, America, Southeast Asia and other international regions.
