1. Door blade,
*48mm aluminum honeycomb core faced both sides with HPL laminate with anti-bacterial treatment(wear proof,moisture proof,impact resistance,antiflaming,antimicrobico,stain resistant charateristic and u can choose the panel color as u like
*Framed in anodized aluminum profiles with rounded edges in aluminum or brushed stainless steel.
2. Door frames&Silicone rubber gasket
*Frame and counter frame in aluminum profile with rounded edges or welded 304L stainless steel suit the hospital door
*Silicone seal gasket are assembled round in the door frame and around the hospial door panel to promise airtightness in the operation room.
3.Observatio Window
Apply double laminated 5mm+5mm safety glass window with round edges and gradient color glass,totally flush on both sides with the door panel
4.Door Handle
304# stainless steel bar handle
5.Automatic Door Operator
*"U" design anodized aluminum track with ramps
*Exclusive 24V brushless motor and controller to ensure the stable and smooth working.
Technical Datas,
| Door model | Single open |
| Steel panel thickness | 2mm |
| Door panel thickness | 50-55mm |
| Radiation equivalent | Max 3mmpb |
| Standard size | 2100mm*1400mm |
| Max capacity | 250KG |
| Open speed(adjustable) | 150mm-600mm/s |
| close speed(adjustable) | 100-500mm/s |
| Activation | foot sensor /hand sensor |
| Infill | aluminum honeycomb&anti-radiation lead |
| Power supply | 230VAC+10/-15%,50/60Hz |
| Working temperature | -20ºC to 50ºC |
| Airtightness standard | GBZ/T147-2002 |
