Square Candy Mold Making Tutorial with HY-6 Silicone Rubber

2 month ago

0 0

Shenzhen Hong Ye Jie Technology Co., Ltd

 8 month year

Product details

The EPS Component Molding industry demands mold-making materials that deliver exceptional precision, reliability, and cost-efficiency. Hong Ye Silicone's addition curing silicone rubber (Model HY-E620) has been specifically formulated to excel in EPS & foam decoration applications.

Based on advanced platinum-catalyzed technology, this liquid silicone rubber delivers:

Near-zero shrinkage (<0.1%)

Outstanding tear resistance (20 kN/m)

Food-safe curing — zero byproducts, zero odor

20 Shore A hardness — optimal balance between flexibility for easy demolding and rigidity for dimensional stability. Viscosity 16000-20000 cps ensures excellent flow and detail capture.

【Key Features】

✅ Platinum Catalyst System — no byproducts, <0.1% shrinkage, no odor, food & skin safe
✅ High Tear Strength (20 kN/m) — mold edges resist splitting, longer mold life
✅ Excellent Flow & Detail Reproduction — self-leveling, captures fine textures
✅ Temperature Stability (-60°C to 200°C) — reliable in any environment
✅ Flexible Mixing (1:1 or 10:1) — 35-50 min pot life, workflow control
✅ Food-Grade Certified — FDA, REACH, RoHS compliant
✅ Extended Mold Life (800-1000+ casts)
✅ Chemical Resistance — compatible with gypsum, cement, GRC, PU foam, epoxy, wax, concrete

【Technical Specifications】

Parameter	Specification
Model	HY-E620
Hardness	20 Shore A
Viscosity	16000-20000 cps
Tear Strength	≥20 kN/m
Tensile Strength	≥5.0 MPa
Elongation	≥400%
Shrinkage	≤0.1%
Mix Ratio	1:1 or 10:1
Pot Life	35-50 min
Cure Time	4-5 hours

【Applications】

EPS Component Molding — decorative elements, exterior insulation panels, foam shapes

Compatible Materials — gypsum, cement/GRC, PU foam, epoxy, wax, concrete

Small-Batch Prototyping — MOQ 2kg, ideal for design validation

High-Volume Production — batch-to-batch ISO 9001 consistency

Custom Color Matching — available for color-coding molds

Training Use — forgiving working characteristics for beginners

【Operating Guide】

1️⃣ Pattern prep → clean + seal + apply release agent
2️⃣ Build mold box → 3-5cm clearance, seal joints
3️⃣ Weigh & mix → ±2% accuracy, stir 3-5 min one direction
4️⃣ Vacuum degas → -0.095 MPa, hold 2-3 min
5️⃣ Pour → thin steady stream from lowest point
6️⃣ Cure → 4-5h at 25°C (or 2h at 60°C)
7️⃣ Demold & inspect
8️⃣ Post-cure 12-24h before first use

【Packaging & Shipping】

1kg / 5kg / 20kg / 25kg / 200kg packages

Shelf life: 12 months

FOB Shenzhen / CIF / DDP / DDU worldwide

Delivery: 3-7 days standard, 7-15 days custom
