BLF06‑00‑00 Threaded Cartridge Valve

Product Overview

BLF06‑00‑00 is a screw‑in threaded cartridge hydraulic valve, installed inside manifold valve block. Compact cartridge‑style structure, no external casting housing required. Mainly applied for pressure relief, over‑pressure safety protection inside hydraulic system. Widely used for small hydraulic power units, engineering machinery, agricultural machinery and special‑equipment hydraulic circuits.

Main Technical Parameters

Item Specification

Model BLF06‑00‑00

Valve cavity size 06‑series threaded cartridge cavity

Max working pressure 210 bar (21 MPa)

Max flow rate 40 L/min

Pressure adjustment range 1.5‑21 MPa

Installation form Screw‑in threaded cartridge, mounted into manifold block

Sealing High‑performance O‑ring seal

Hydraulic medium Anti‑wear hydraulic oil ISO‑VG32 / VG46

Operating temperature ‑10℃ ~ +70℃

Filtration requirement ≤25 μm

Working Principle

It is direct‑acting poppet‑type relief cartridge valve.

1. When system pressure is lower than preset spring force, poppet stays closed, oil does not overflow.

2. Once hydraulic pressure exceeds setting value, poppet opens, excess oil flows back to tank inside manifold, so as to limit and stabilize system working pressure.

3. Protect hydraulic pump and actuators against pressure overload.

Core Advantages

1. Threaded cartridge design, embedded installation inside manifold block, save installation space, simplify piping layout.

2. Poppet‑type sealing, low internal leakage, reliable pressure‑holding performance.

3. Compact size, easy for mass assembly inside integrated hydraulic manifold.

4. Replaceable cartridge core, convenient maintenance and spare‑parts replacement without changing whole valve block.

5. Good interchangeability for industry‑standard 06‑size cartridge cavity.

Typical Application

Small hydraulic power pack, material‑handling equipment, agricultural machinery, construction machinery auxiliary hydraulic circuit, general‑purpose industrial hydraulic station. Used for system pressure limiting and over‑pressure safety protection.
