Hong Ye HY-E630 is a 30 Shore A addition-curing liquid silicone rubber engineered specifically for large-format and heavy-duty mold making applications. Built on a platinum-catalyzed hydrosilylation system, this industrial-grade silicone delivers an exceptional combination of structural rigidity, high tear resistance (≥24 kN/m), and near-zero shrinkage (≤0.1%) — making it the material of choice for large sculpture reproduction, GRC facade panels, theme park rockwork, concrete architectural elements, and high-volume production molds.
What distinguishes HY-E630 from softer grades is its optimized crosslink density. At 30 Shore A, the cured silicone offers enough firmness to maintain dimensional stability under the weight of heavy casting materials (concrete, GRC, filled resins) while retaining sufficient elasticity for clean demolding of undercuts and complex geometries. The translucent formulation allows visual bubble inspection during pouring, and the dual mix-ratio option (1:1 or 10:1 by weight) provides process flexibility for both large pour-in-place molds and fast-turnaround small-batch work.
Manufactured by Shenzhen Hong Ye Jie Technology Co., Ltd. — a silicone specialist with 25+ years of experience and exports to 138+ countries — HY-E630 is backed by full ISO 9001, FDA, REACH, RoHS, UL, and CE certifications, ensuring compliance with the most demanding international quality and safety standards.
1. High Tear Strength for Demanding Production With a tear strength of ≥24 kN/m and tensile strength of ≥6.0 MPa, HY-E630 withstands the aggressive demolding forces encountered in large sculpture and concrete mold applications. Molds resist tearing at sharp edges, deep undercuts, and thin flange sections — delivering 800–1,200 casting cycles per mold in typical GRC and concrete production environments.
2. Near-Zero Shrinkage for Dimensional Precision The platinum addition-cure mechanism releases no volatile by-products, keeping cure shrinkage below 0.1%. A 1-meter master pattern yields a mold within 1 mm of the original dimension — eliminating the pattern scaling, test pours, and rework associated with condensation-cure silicones that shrink 0.3%–0.5%.
3. Structural Stability for Large Molds At 30 Shore A hardness, HY-E630 provides the rigidity needed to support large, heavy molds without sagging or deforming under their own weight. This is especially critical for vertical wall molds, large sculpture sections, and molds that must be stored or transported between production runs.
4. Alkali and Chemical Resistance HY-E630 is inherently inert to alkaline cement, GRC slurry, epoxy resin, polyurethane, gypsum, and wax. It does not react with, bond to, or degrade when exposed to these casting materials — ensuring consistent release performance and long service life even in high-volume cementitious casting operations.
5. Wide Temperature Tolerance Service temperature range of -60°C to +200°C covers cold-climate outdoor storage, heated curing ovens, and the exothermic heat generated by curing concrete and resin. The silicone retains elasticity and mechanical properties across this entire range.
6. Dual Mix Ratio for Process Flexibility
7. Translucent for Quality Control The semi-transparent appearance allows operators to visually inspect for air bubbles, incomplete filling, and cure progression during production — reducing defect rates and minimizing scrap.
表格
| Property | Test Standard | Value |
|---|---|---|
| Appearance | Visual | Translucent |
| Hardness | GB/T 531 | 30 Shore A |
| Viscosity | GB/T 10247 | 20,000–25,000 cps |
| Tear Strength | GB/T 529 | ≥24 kN/m |
| Tensile Strength | GB/T 528 | ≥6.0 MPa |
| Elongation at Break | GB/T 528 | ≥400% |
| Cure Shrinkage | In-house Standard | ≤0.1% |
| Service Temperature | — | -60°C to +200°C |
| Mix Ratio | — | 1:1 or 10:1 (by weight) |
| Pot Life @ 25°C | — | 45–60 minutes |
| Demold Time @ 25°C | — | 4–6 hours (2 hrs @ 60°C) |
| Shelf Life | Sealed, cool & dry | 12 months |
表格
| Package | Size | Typical Use |
|---|---|---|
| Bottle | 1 kg | Sampling, small workshops, prototyping |
| Pail | 5 kg | Small production, trial orders |
| Drum | 20 kg | Standard production size |
| Drum | 25 kg | Bulk economy option |
Shenzhen Hong Ye Jie Technology Co., Ltd., established in 1998, is a national high-tech enterprise specializing in the R&D, manufacturing, and sales of silicone rubber products. With a 6,000 m² modern production facility and monthly capacity exceeding 220 tons, Hong Ye serves customers in 138+ countries across 20+ industries — including construction, food processing, automotive, medical devices, electronics, and arts & crafts.
Our in-house quality laboratory ensures batch-to-batch consistency, and our technical team provides formulation support, process optimization, and after-sales service for custom applications.
