DHF10‑227L‑D Bi‑directional Normally‑Open Threaded Cartridge Valve

Product Overview

DHF10‑227L‑D is a 10‑size bi‑directional normally‑open screw‑in cartridge solenoid valve for hydraulic system. Under power‑off condition, the oil passage keeps bi‑directional conducting. When energized, the valve spool acts to cut off the oil flow in both directions. Equipped with manual override knob for emergency manual operation. Widely used in hydraulic power units, lifting machinery, mobile equipment and safety protection circuits of hydraulic system.

DHF10‑227L‑D Normally‑Open Threaded Cartridge Valve is an electromagnetic operated switching Hydraulic valve. As a screw-in CARTRIDGE VALVE, it acts as an essential automatic control component within the hydraulic system. This threaded CARTRIDGE VALVE can be directly screwed into integrated manifold blocks, eliminating complex external pipelines and optimizing layout to make the entire hydraulic system compact and simplified. As a normally open type Hydraulic valve, its fluid channel stays open under power-off status. When energized, it rapidly closes the oil passage, meeting automatic loop control requirements of industrial equipment and mobile machinery hydraulic system.

Main Technical Parameters

Item Specification

Model DHF10‑227L‑D

Valve cavity size 10 standard cartridge cavity

Structure Spool‑type bi‑directional normally‑open threaded cartridge solenoid valve

Max working pressure 210 bar

Rated flow 50 L/min

Coil voltage option DC12V, DC24V

Installation Screw‑in cartridge mounting into manifold block

Manual override Available

Seal material NBR O‑ring, FKM for high‑temperature option

Hydraulic fluid Anti‑wear hydraulic oil ISO‑VG32 / VG46

Operating temperature ‑10℃ ~ +70℃

Required filtration ≤25 μm

Working Principle

1. De‑energized state (Normally‑Open): The return spring holds the spool at original position. The internal oil port remains bi‑directional open, hydraulic oil can flow freely in both directions.

2. Energized state: Electromagnetic force drives the spool to shift, blocks the bi‑directional oil passage, cuts off oil flow of the circuit.

3. Manual override function: The red knob on valve top can push spool mechanically for emergency operation during power failure, resets automatically after releasing.

4. When power is cut off, return spring pushes spool back to normally‑open position automatically.

Core Advantages

1. Standard 10‑size cartridge dimension, compatible with general 10‑size manifold block cavities.

2. Bi‑directional normally‑open function: pass oil when power off, shut‑off when power on, suitable for safety lock‑off loop.

3. Built‑in manual override, convenient for commissioning and power‑off emergency operation.

4. Coil is independently replaceable, no need to remove whole valve cartridge for maintenance.

5. Compact screw‑in structure, reduces pipeline fittings, makes hydraulic system layout neat.

Application Scope

Hydraulic power packs, aerial work platforms, lifting equipment, engineering machinery auxiliary circuits, safety protection and on‑off control loops of industrial hydraulic system.
