Product details

1. Product Overview

As one of China’s leading manufacturers and suppliers of Plunger Safety Switches, YESWITCH develops and manufactures this Seat Safety Switch. This Momentary Plunger Seat Switches adopts (ON)‑OFF momentary function, built for operator‑presence safety interlock for riding‑type outdoor machinery.

Our core services include standard unit supply, pre‑production sample validation and quick technical support for global OEM customers. Many riding‑equipment failures stem from unstable seat sensing switches. This unit solves that pain point, helping buyers lower field‑failure risk for lawn mowers, golf carts and compact forklifts.

2. Core Performance & Technical Specifications

This Mower Plunger Safety Switch delivers consistent performance under wide‑range temperature and humidity conditions, well‑suited for heavy‑duty outdoor safety‑interlock circuits.

Specifications

‑ Operating Pressure:1200gf ±200gf

‑ Operating Stroke:9.5mm ±1.0

‑ Function:(ON)-OFF Momentary

‑ Body:PP,UL rated:94V‑2 Black

‑ Plunger:PP,UL rated:94V‑2 Black

‑ Terminal:Brass,Gold plate

‑ Rating: 3A 12VDC,5A 24VDC

‑ Contact Resistance:50mΩ MAX

‑ Insulation Resistance:100MΩ MIN

‑ Dielectrical life:10000 cycles

‑ Mechanical life:75000 cycles

‑ Operating Temperature:-40°C~85°C

‑ Relative Air Humidity:45%~85%

Gold‑plated brass terminals restrain oxidation in damp surroundings. With 75 000 mechanical cycles, the switch keeps steady signal output even after frequent triggering. It serves as dependable safety interlock hardware for end‑product compliance.

3. Custom Support & Application Scenarios

Our Interlock Plunger Safety Switch accepts reasonable modification to fit different project‑mounting requirements.

Internal‑link words: custom bracket adaptation, terminal form adjustment, batch pre‑shipment electrical test

We support bracket‑form adjustment upon client requests. Every batch will pass full‑function electrical inspection before shipment. It is widely deployed on riding mowers, golf carts and small‑size forklifts. Our engineering team offers timely consultation for your assembly and specification matching.
