Product details

PP-C Sheet, Gray, Custom, Chemical Equipment . Accurate Solutions . No Surface Film Fabrication . Film Adhesive Fabrication Friction of Surface Film Adhesives.

Industrial panels usually have protective covers that leave a sticky residue when removed. It catches airborne dust, clogs CNC routing tools, and destroys plastic welding seams.

The custom grey PP Sheet overcomes this processing barrier. It is produced without a surface film, eliminating cleaning steps, so shops can move panels directly from inventory to the CNC router or welding bench.

Technical Summary of Performance

Properties	Standard	Unit	Test Data
Specific gravity	ISO 1183	g/cm³	0.91
Water absorption	ISO 62	%	＜0.1
Flammability	UL94	/	HB
Mechanical Properties
Yield stress	ISO 527	Mpa	30.2
Elongation at break	ISO 527	%	19
Tensile modulus of elasticity	ISO 527	Mpa	1210
Notched impact strength	ISO 179	kJ/m²	7.36
Notched izod impact strength	ISO 180	kJ/m²	7.16

Zero Glue Residue Processing

Normal panels use temporary films that degrade with heat or long storage. The Non-film grey Polypropylene Plastic Sheets is shipped bare and offers a smooth matte surface.

Clean Surface : Panels can be wiped down with no chemical solvents for processing.

CNC Tool Preservation : How to Avoid Sticky Build-Up on CNC Bits to Help Maintain Cutting Edge Sharpness

Direct Joining : Welding rods of plastic are joined without contamination by dissolved adhesive residues.

Copolymer Chemistry for Mechanical Equilibrium： This structural design offers improved impact resistance relative to conventional homopolymer versions, especially at lower operating temperatures.

When making custom tanks, the balanced flexibility prevents cracking around punched holes, rivet points or tight bend radii.

Chemical Resistance Properties

Structural materials for industrial process environments must tolerate continuous exposure to corrosive liquids

Compatibility with Media

Acids: Resists sulphuric acid up to 70% and solutions of hydrochloric acid.

Alkalis: Not affected by sodium hydroxide and potassium hydroxide wash baths.

Solvents: Maintains structural integrity in the presence of inorganic salt solutions and alcohol.

The polymer structure is non-polar and does not absorb fluid and in fluid collection systems there is no swelling or thinning of the walls.

Primary Use Cases

Chemical Pickling Tanks : High acid resistance & good welded joints

Scrubbing Towers : Low density reduces the load on the structural frame [ Electroplating Baths ] Heavy Metal Parts Impact Strength Handles

Chemical Storage & Pickling Baths

Fabricators employ these panels in the fabrication of acid pickling tanks, plating tubs, and neutralisation vessels. Smooth matte surface for easier fillet welds, with standard PP welding rod.

Ventilation and Ducting Systems

Lightweight materials with high tensile strength are required for fume extraction hoods and wet scrubbing towers. This material reduces total system weight and continuously handles corrosive vapour streams.

Machining Parts for Industry

These Polypropylene Plastic Sheets are cut in machining shops into custom baffles, valve bodies, flange gaskets and filter press plates. The copolymer composition provides clean edges without burr build-up during high-speed milling.

Custom Sizing & Wholesale Specifications

Thickness : Normal 1mm to 150mm

Standard Sizes: 1000*2000mm, 1300*2000mm, 1220*2440mm, 1500*3000mm

Custom Options: Custom lengths, custom thickness tolerances and colour matching are available on request.

FAQs

Q: Why choose a custom grey PP-C sheet without protective film?

A: Film adhesives leave sticky glue on plastic panels. This residue takes time to remove and damages CNC tools Our non-film sheets are cut and ready for welding immediately.

Q: Is this sheet suitable for plastic welding?

A: Yes. There is no film residue that leaves the surface clean. Standard PP welding rods fuse cleanly with no adhesive contamination to weaken the joint.
