SOLENOID VALVE DSV-G02-2A-DC24-90

Product Overview

DSV-G02-2A-DC24-90 is a solenoid operated directional Hydraulic valve, widely used as flow direction control component for the hydraulic system of industrial Machine. This Hydraulic valve adopts NG6 standard mounting surface (ISO4401), 2-position single solenoid spring return structure, DC24V coil power supply. It switches the flow path of hydraulic oil to control the action of hydraulic cylinders and actuators inside the hydraulic system.

This solenoid Hydraulic valve is the 7OCEAN seven ocean DSV-G02 series directional valve. It has stable reversing performance, low friction and reliable sealing. As a core control part, it can quickly change the oil flow direction of the hydraulic system, realizing clamping, lifting and telescoping actions of the Machine.

Technical Specifications

- Model: DSV-G02-2A-DC24-90

- Product Type: Solenoid directional Hydraulic valve

- Mounting standard: ISO4401 NG6

- Coil voltage: DC24V

- Spool function: 2A spool, two-position single solenoid with spring return

- Max working pressure: 35MPa

- Rated flow: 40L/min

- Working medium: Anti-wear hydraulic mineral oil

- Protection grade: IP65

- Application: Direction control of hydraulic system for industrial Machine

- Feature: Quick response, low noise, long service life

Working Principle

When the Machine energizes the DC24V solenoid coil of this Hydraulic valve, electromagnetic force pushes the valve spool to shift, changing the internal oil passage connection of the hydraulic system. High-pressure hydraulic oil flows to the designated actuator to drive the Machine to perform preset actions. Once power is cut off, the reset spring pushes the spool back to its original position, switching the oil circuit back and stopping the movement of the actuator. This Hydraulic valve accurately controls the direction of hydraulic oil and ensures safe and orderly operation of the whole hydraulic system.

Core Advantages

1. Standard ISO4401 NG6 installation size, easy assembly and interchangeability for the hydraulic system of Machine.

2. High-precision ground valve spool design, small internal leakage, smooth reversing, no stuck phenomenon.

3. DC24V solenoid coil with IP65 protection, good dustproof and waterproof performance, suitable for factory workshop environment.

4. Spring return structure, fast response speed, stable and repeatable reversing action for the hydraulic system.

5. Widely used for hydraulic power station, machine tool and automation equipment maintenance and assembly, easy spare part stocking.

Application Range

DSV-G02-2A-DC24-90 Hydraulic valve serves as directional control element in hydraulic system of hydraulic power packs, injection molding machines, machine tools, automation jigs and other industrial Machine. It is used to control hydraulic cylinder expansion and contraction for equipment assembly, overhaul and spare parts replacement.
