Product Description:

Huizhou Antenk Electronics Co., Ltd. manufactures 4P 2.50mm pre assembled harness cables to achieve reliable power and signal transmission between printed circuit boards and internal electronic modules. This finished wire to board harness adopts 2.50 millimeter pitch four position configuration and supports custom wire length and wire gauge selection with stable crimp terminal locking construction for convenient direct plug in installation without additional soldering procedures. It applies to digital household appliance internal wiring industrial control module interconnection communication device signal delivery and compact consumer electronic equipment assembly. Users align and insert the cable connector onto matching board mounted header to form complete electrical connection. Operators must avoid excessive pulling force and harsh bending during installation keep full connector engagement and store finished harness goods in dry environment to prevent metal terminal oxidation. Unlike competitors who outsource harness manufacturing Antenk completes full in house procedures including wire cutting stripping terminal crimping connector assembly and strict laboratory continuity testing. Our factory holds ISO9001 ISO14001 IATF16949 and UL certifications and over seventy percent of connector products are exported worldwide. Please share your custom wire specifications and project details for free sample evaluation and complete technical document support.

1. Short Pitch Harness Cable delivers compact signal and power connection for space limited electronic module layouts.

2. Equipment Internal Harmess Cable serves as built in wiring link inside various household and industrial electronic devices.

3. Multi Module Harness enables stable signal transmission among multiple functional units within one electronic system.

Detailed Specifications:

1. Mechanical Specifications

1.1 Product type: 4 positions 2.50 millimeter pitch pre assembled wire to board assembly cable

1.2 Measurement unit: millimeter

1.3 Key feature: Standard wire length 80±5 mm, wire stripping dimension 4.0±1 mm. Available wire color options include black brown red and orange. Every finished unit passes one hundred percent continuity test.

1.4 Assembly method: Pre crimped finished harness for direct plug in connection

1.6 CTA: Contact our engineering team to get complete dimension drawings for your mechanical design validation.

2. Material Construction

2.1 Compliance: Comply with RoHS 2.0 and HSF lead free requirements

2.2 Wire feature: Multi‑color insulated wire with four color selections for circuit identification

3. Electrical & Performance Parameters

3.1 Inspection standard: One hundred percent electrical continuity testing for each finished cable

3.2 Note: Full current voltage and insulation parameters are available in official datasheet, please request technical documents for complete electrical performance data.

4. Usage Method

4.1 Assembly mode: Insert cable connector onto corresponding board mounted header to complete circuit connection

4.2 Operation tip: Confirm full insertion engagement to guarantee reliable electrical conduction.

5. Application Scenarios

5.1 Digital household appliance internal circuit wiring

5.2 Industrial control module signal and power interconnection

5.3 Communication equipment internal module connection

5.4 Compact consumer electronic device assembly

6. Operation & Storage Precautions

6.1 Follow drawing dimension tolerance during product structural design

6.2 Avoid excessive pulling force and sharp bending to prevent wire damage or terminal disconnection

6.3 Do not scratch wire outer insulation layer in installation process

6.4 Keep finished assembly cables under dry storage condition to avoid metal terminal oxidation

6.5 Verify pin count wire length and wire color requirement before procurement and project design

6.6 CTA: Submit your customized dimension color and project requirements, we provide free sample evaluation and professional technical consultation services.
