SUN RVEALWN Hydraulic Cartridge Valve

Product Overview

SUN RVEALWN is a pilot-operated balanced piston relief CARTRIDGE VALVE, a high-performance Hydraulic valve for pressure limiting and overload protection. It serves as a critical pressure control component inside the hydraulic system of various Machine, including mobile construction machinery, deck equipment and industrial hydraulic power units. The screw-in cartridge design can be installed directly into standard T-2A manifold cavity, which simplifies manifold processing and flexible circuit layout.

Technical Specifications

- Model: RVEALWN

- Type: Pilot-operated balanced piston relief CARTRIDGE VALVE

- Cavity: T-2A

- Max operating pressure: 350 bar (5000 psi)

- Rated flow: 120 L/min (30 gpm)

- Pressure adjustment range: 35 ~ 350 bar

- Feature: With vent port for remote pressure control

- Factory pressure setting tested at 15 L/min flow

Working Principle

As a reliable Hydraulic valve, this CARTRIDGE VALVE adopts pilot operated balanced piston structure. When the inlet pressure of the hydraulic system exceeds the preset value, the valve opens and diverts excess hydraulic oil back to tank to limit system pressure. The vent port supports remote pressure adjustment via external pilot valves, which brings flexible pressure control for the Machine. It maintains stable pressure even under variable flow conditions.

Core Advantages

1. Excellent pressure regulation stability, small pressure rise with flow increase, low noise during operation.

2. Balanced piston design reduces mechanical friction, improves service life for continuous-duty hydraulic system.

3. Built-in remote control vent port, convenient for remote unloading and pressure regulation on the Machine.

4. Compact screw-in CARTRIDGE VALVE structure, easy to replace without disassembling the whole manifold block.

5. High pressure resistance and strong anti-pollution ability, works reliably under harsh working conditions.

Application Range

This SUN Hydraulic valve is widely applied for pressure overload protection and pressure regulation in the hydraulic system of engineering Machine, material handling equipment, marine deck machinery, hydraulic power pack and other industrial hydraulic facilities. It is commonly used for main circuit pressure limiting, remote unloading and safety protection circuits.
