PV High Pressure Pumps

Product Overview

PV High Pressure Pumps (Parker PV series) is swashplate variable displacement axial piston pump designed for open-circuit hydraulic system. It converts rotary mechanical power into high-pressure hydraulic energy, serving as the high-performance power core for heavy-duty industrial Machine. Adopting 9-piston structure, this pump features low flow pulsation, high volumetric efficiency and modular control design. It is widely preferred for precision industrial hydraulic equipment, supporting multiple control modes and full through-drive for flexible hydraulic system layout.

Technical Specifications

- Model range: PV016, PV020, PV023, PV028, PV032, PV040, PV046, PV063, PV080, PV092, PV140, PV180, PV270

- Displacement: 16 ~ 270 cm³/rev

- Nominal pressure: 350 bar

- Peak pressure: 420 bar

- Structure: Swashplate axial piston, 9 pistons

- Control options: Pressure compensator, load sensing, constant power, remote pressure control, electro-proportional control

- 100% through-drive available, can combine with gear pump or another piston pump, twin pump assembly optional

- Speed range: 300 ~ 3600 rpm

- High volumetric efficiency up to 95%

Working Principle

When drive shaft rotates, cylinder block and piston-slipper assemblies revolve together. Pistons slide on inclined swashplate and perform reciprocating axial movement to complete oil suction and discharge. Adjusting swashplate tilt angle changes piston stroke, so displacement and output flow can be steplessly adjusted. When the hydraulic system pressure reaches preset value, the compensator automatically reduces pump displacement to maintain stable pressure and save energy. The pre-compression design reduces pressure pulsation and vibration for smoother operation.

Key Features

1. 9-piston optimized structure, low flow pulsation, low noise and stable output

2. Heavy-duty cast iron housing, high power density, continuous stable operation under 350 bar

3. Modular control cover design, easy replacement of control functions for different requirements

4. Full through-drive design, support single pump or double pump combination, simplify your Machine hydraulic circuit

5. Excellent volumetric efficiency, lower heat generation and energy consumption during standby

6. Wide speed range, good anti-contamination performance, long service life

7. Multiple port and flange options, convenient installation for compact machine layout

Application

- Plastic machinery: injection molding machine, blow molding machine

- Metal forming: hydraulic press, die casting machine, forging equipment

- Machine tools: CNC machine, bending machine, hydraulic power unit

- Mining & metallurgy: metallurgical rolling equipment, mining auxiliary machinery

- Marine & mobile equipment: deck machinery, heavy-duty special vehicles

adiffer-dpvb-dpve-variable-piston-pump-vickers-type-1
