Nabtesco Original Swing Motor PCL-200-18B

This Nabtesco (Nachi) original swing motor assembly, model PCL‑200‑18B, is a widely used slewing drive component for 5–6 ton mini excavators. It is driven by the main hydraulic pump, the excavator’s Hydraulic piston pump, and works as the core rotary power part of the whole hydraulic system, delivering steady slewing torque to rotate the upper structure of your Machine.

Technical Parameters

- Model：PCL‑200‑18B

- Displacement: 80 ml/r

- Rated Working Pressure: 28 MPa

- Max. Pressure: 31.5 MPa

- Built‑in multi‑stage planetary reduction gear set

- Integrated static parking brake: prevent body slipping on slopes

- With built‑in shock relief valve, buffer the pressure surge during swing start & stop

- Complete assembly (motor + reducer + brake + valve assembly)

- Installation: OEM standard mounting dimension, direct replacement without machining

The swing motor features compact structure, high torque output and low internal leakage. It can effectively eliminate common defects: slow swing speed, insufficient slewing force, drifting after stop, abnormal noise and oil leakage. Every finished unit will be strictly inspected and pressure tested before delivery. It is the perfect overhaul replacement part for mini excavator slewing failure.
