Product details

Plate vulcanizing machines are specialized equipment widely used in the molding and processing of rubber and silicone products, such as silicone watch straps. Their core function is to apply controlled pressure and precise temperature to raw rubber/silicone materials within a set time, promoting material vulcanization (cross-linking reaction) to form products with fixed shapes and stable performance.

Name	30T single head hydraulic machine	50T single head hydraulic machine	63T single head hydraulic machine	100T single head hydraulic machine
Model	JY-A02	JY-A02	JY-A02	JY-A02
Voltage	380V	380V	380V	380V
Max working pressure	30	50	63	100
Wore area	350*350mm	350*400mm	400*400mm	450*450mm
Power	3.7kw	5.5kw	5.5kw	5.5kw
Heating Power	10.8kw	10.8kw	10.8kw	10.8kw
Total Power	14.5kw	16.3kw	16.3kw	16.3kw
Max temp	400℃	400℃	400℃	400℃
Main cylinder diameter	150mm	180mm	200mm	250mm
Main cylinder stroke	160mm	160mm	250mm	250mm
Size	125015001550mm	130016001550mm	140018601780mm	140018601780mm
Weight	1000kg	1500kg	2000kg	2500kg

Key features typically include: Jinyu Machinery's Silicone single head hydrualic machine (Silicone Machines)

• Stable structure: Common four-column three-beam design, with thickened upper seats and hardened columns to withstand high pressure without deformation during operation.

• Accurate temperature control: Temperature adjustment range is usually from room temperature to 400℃, with intelligent temperature control technology to keep the temperature fluctuation within ±2℃, meeting the strict temperature requirements of different rubber/silicone products.

• Easy operation: Equipped with PLC and touch screen control system, allowing free setting of parameters like deflation time, deflation times, and vulcanization time. It also supports both manual and automatic working modes for flexible operation.

• Energy efficiency and high performance: The heating plate adopts deep-hole processing technology, closely matching the heating tube to reduce heat loss. The optimized oil circuit system with high-quality components ensures stable operation and high production efficiency.
