MAR-BS5/8 00550-005 Breakaway Swivel

The MARSHINE MAR-BS5/8” 00550-005 Breakaway Swivel is a compact cable pulling accessory designed to combine swivel action with overload protection during cable and utility installation. By incorporating a rotating connection with a replaceable breakaway pin, it helps reduce twisting in the pulling system while providing a controlled release point when the preset pulling load is reached.

The MARSHINE Breakaway Swivels are particularly useful for applications where excessive pulling tension could damage the cable, conduit, duct, or other utility being installed. The breakaway pin can be selected according to the required breaking load, allowing the same swivel body to be used with different rated pins. The reference design uses quick-change interchangeable pins, which can be replaced between pulling operations. The MAR-BS5/8 features a 5/8-inch (16 mm) swivel size, 3-1/4-inch (82.5 mm) overall length, steel swivel construction, and a lightweight 77.1 g design. It is suitable for cable pulling systems where compact dimensions, controlled pulling force, and smooth rotation are important.

Product Feature

Built-In Swivel Function

Allows rotational movement during pulling to help reduce twisting and torsional stress in the cable pulling system.

Breakaway Overload Protection

A replaceable breakaway pin provides a predetermined release point to help protect the installed utility from excessive pulling tension.

Interchangeable Breakaway Pin

Different breakaway pins can be selected according to the required pulling-load setting, allowing flexible use for different installation conditions.

Steel Swivel Construction

The steel body provides a durable connection for professional cable pulling operations.

Aluminum Breakaway Pin

The aluminum pin is designed as the replaceable breakaway element for controlled overload release.

Compact 5/8-Inch Design

The 16 mm swivel size provides a compact connection for cable pulling assemblies where installation space is limited.

Lightweight Construction

At only 77.1 g, the MARSHINE MAR-BS5/8 Light Duty Breakaway Swivel adds minimal weight to the pulling system.

Quick Pin Replacement

The breakaway pin can be changed when a different load setting is required or after a breakaway event.

Product Application

Our MARSHINE MAR-BS5/8” 00550-005 Breakaway Swivel Joint is designed for cable pulling, utility installation, and line-stringing applications where both rotational movement and controlled overload protection are required. It can be installed between a pulling rope and the cable or utility being installed. During pulling, the swivel allows the connected components to rotate relative to each other, helping minimize twisting. If the pulling force reaches the selected breakaway-pin capacity, the pin is designed to release, providing a controlled overload protection mechanism.

Technical Parameters

Model	MAR-BS5/8
Pin capacity	125lb (56.7kg)
Swivel Size	5/8”(16 mm) x 3-1/4” (82.5 mm)
Swivel material	Steel
Pin material	Aluminum
Weight	77.1 g

PRODUCT DISPLAY
