Pneumatic Connector, Plastic Pneumatic Connector, Pneumatic Quick Connector
Pneumatic connector is a kind of quick joint which is widely used in air configuration and pneumatic tools. It can connect or disconnect the pipe without any tools
Quick plug connector is the most convenient plug and play connection mode, especially in some air pipe connection is very inconvenient, difficult space occasions, can reflect the advantages of quick plug connector.
PC4-M5 | PC10-01 | For example:PC6--01(G)(1)(2)(3)(4) | ||
PC4-01 | PC10-02 | (1)Model: PC | ||
PC4-02 | PC10-03 | (2) Tube OD(mm) | ||
PC4-03 | PC10-04 | Metric: 3/4/5/6/7/8/9/10/11/12/13/14/15/16 | ||
PC6-M5 | PC12-01 | English: 1/8'' 5/32'' 3/16'' 1/4'' 5/16'' 3/8'' 1/2'' | ||
PC6-01 | PC12-02 | (3)Thread Size | ||
PC6-02 | PC12-03 | Metric: M3/M5/M6/M8/M10/M12/M14/M16/M22 | ||
PC6-03 | PC12-04 | English: 01:1/8'' 02:1/4'' 03:3/8'' 04:1/2'' | ||
PC6-04 | PC14-03 | (4)Inch thread form: | ||
PC8-01 | PC14-04 | Default: BSP(BSPP/G) | ||
PC8-02 | PC16-02 | (PT): BSPT(R) | ||
PC8-03 | PC16-03 | (N): NPT(Z) | ||
PC8-04 | PC16-04 |
Specifications:
Male Thread Size | BSP 1/8'' |
Medium | Air - Water - Vacuum |
Apply For | 8mm tube/hose |
Applicable Tube | PU / PA / PE / PVC |
BSP Thread Data |
1/8" BSP thread---------Thread Outside Diameter: 9.728mm 1/4" BSP thread---------Thread Outside Diameter: 13.157mm 3/8" BSP thread---------Thread Outside Diameter: 16.662mm 1/2" BSP thread---------Thread Outside Diameter: 20.955mm 3/4" BSP thread---------Thread Outside Diameter: 26.441mm 1" BSP thread-----------Thread Outside Diameter: 33.249mm |
Note |
1.Due to the difference between different monitors, the picture may not reflect the actual
color of the item. and quantities for your choice,the more your purchase the best price you get. Thank you! |
