Product details

AISI 1020/1045 is one of the standards which is most suitable for multiple industrial applications. AISI 1020/1045 is the most appropriate grade and is also widely demanded by industries. This Steel grade, i.e. AISI 1020/1045, is applicable for both the cold drawn as well as hot rolled forms. These grades are available in a wide range of sizes and forms. Our company are manufacturer and supplier of all types of Pipes. By considering the needs and demands of all industries, we fabricate different kinds of Pipes by using various materials and alloys. AISI 1020 carbon steel pipe are applicable in industries to complete applications such as engineering machinery, hydraulic equipment, and agricultural machinery.

Carbon Steel Pipe

We are fabricating and exporting high-quality AISI 1020/1045 Pipes in different sizes, thicknesses, and dimensions. We are focusing on supplying perfectly suitable Pipes within a decided time and at affordable rates. We have highly qualified, skilled, experienced professionals in our team who are working to deliver the most excellent quality Pipes with superior finishing. This helps us to produce AISI 1020/1045 Pipes faster and in bulk amounts.

Our company is mainly focusing on serving excellence in minimum time as well as at a reasonable cost. Without compromising on quality, we produce AISI 1020/1045 Pipes in large quantities. With proper packing and shipping ways, we deliver the highest quality product safely.

Out Diameter	13.7mm-914mm
Wall Thickness	2mm-120mm
Length	2m-12m
Producing Standard	American ASME B36.10M, ASTM API 5L, API 5CT, Japanese JIS, German DIN, Chinese GB, BS standard
Steel Grade	ASTM A53, A106, A210, A252, A178, A333, A335, SAE1018, SAE1020, SAE1045 etc; API 5L PSL1: A, B, x42, x46, x52, x56, x60, x65, x70 API 5L PSL2: B, x42, x46, x52, x56, x60, x65, x70, x80 JIS SS400, STPG42, G3454, G3456 etc; DIN St35, St35.8, St37, St42, St45, St52, DIN1626, DIN17175 etc; GB 10#, 20#, 45#, Q235, Q345, Q195, Q215, 16Mn, 27SiMn, 20Cr, 40Cr, 12CrMo, 15CrMo, 30CrMo, 35CrMo, 42CrMo etc; EN S235JR, S275JR, S355JR, S355J0, S355J2
Special specifications	Available according to customer's requirements and quantity.
End Shape	Beveled end, plain end, varnished, or adding plastic caps to protect the two ends as per customer's requirements
Surface treatment	Painted, Oiled, galvanized, phosphate etc
Usage	1.Widely used in the mechanical treatment field, petrochemical industry, transport and construction field 2.Ordinary structural purposes and mechanic structural purposes, for example in construction field, fulcrum bearing etc; 3.The transportation of fluids in the projects and big equipments, for example transport of water, oil, gas etc 4.Can be used in low and medium pressure boiler for the transportation of fluids, for example steam tube, big smoke tube, small smoke tube, generating tube etc
Third party inspection	Welcome you to send a third party inspecting company (BV, SGS etc) to check the quality of our final products.

45# 45#

ASTM 1020/ 1045 Seamless Steel Pipe

Chemical Composition of seamless steel pipe

Material	Chemical composition (%)
Material	C	Si	Mn	P	S	Ni	Cr	Cu
10#, ASTM 1010, DIN CK10, JIS S10C	0.07~0.13	0.17~0.37	0.30~0.60	≤0.035	≤0.035	≤0.25	≤0.20	≤0.25
20#, ASTM 1020, DIN CK20, JIS S20C	0.17~0.24	0.17~0.37	0.35~0.65	≤0.035	≤0.035	≤0.25	≤0.25	≤0.25
35#, ASTM 1035, DIN CK35, JIS S35C	0.32~0.38	0.17~0.37	0.50~0.80	≤0.035	≤0.035	≤0.30	≤0.25	≤0.25
45#, ASTM 1045, DIN CK45, JIS S45C	0.42~0.50	0.17~0.37	0.60~0.90	≤0.035	≤0.035	≤0.25	≤0.25	≤0.25

Mechanical Properties of seamless steel pipe

Steel material	Tensile strength Mpa	Yield strength Mpa	Elongation %	Hardness	Straightness
10#, ASTM 1010, DIN CK10, JIS S10C	≥335	≥205	≥31	≤137HB	0.3~1.0
20#, ASTM 1020, DIN CK20, JIS S20C	≥410	≥245	≥25	≤156HB	0.3~1.0
35#, ASTM 1035, DIN CK35, JIS S35C	≥530	≥315	≥20	≤197HB	0.3~1.0
45#, ASTM 1045, DIN CK45, JIS S45C	≥600	≥355	≥16	≤HRC62	0.3~1.0

We can produce different sizes, thicknesses, widths and materials according to your requirements
