Manual Operated Hydraulic Monoblock Directional Control Valves:
1. P40 series valves with middle-high pressure monoblock construction is developed based on Europe technology.
2. Inner check valve: The check valve inside the valve body is to insure the hydraulic oil not to be returned.
3. Inner relief valve: The relief valve inside the valve body is able to adjust the hydraulic system working pressure.
4. Oil way: Parallel circuit, power beyond option
5. Control Way: Manual control, pneumatic control, hydraulic and electric control for optional.
6. Valve construction. monoblock construction, 1-7 levers.Spool Function: O,Y, PA.
7. Option: Hydraulic lock is available to be added on A and B port.
8. Available with manual,' pneumatic control, electric and pneumatic control, hydraulic and electric control and etc.
1.We accept Paypal, credit card, debit card, Google Pay...
2.Shipping will be arranged within 7 business day once payment is cleared.
Name
3 Spool P40 Hydraulic Directional Control Valve
Max operating pressure
P = 3600psi (250 bar);T = 150psi (10 bar); A ,B = 4300psi (300 bar)
Nominal flow
13gpm (60L/min)
Relief valve
Adjustable
Center system
Open
A, B ports
3/8" BSPP
P, T, N port
1/2" BSPP
Applications
Small tractors,Tractors loaders,Log splitters,Other mobile.
Payment
Contact Us& Feedback
If there is any fault or problem with the product, please don't be shy to express it, we will solve it at the first time.
Construction
Р40 is a mono-bloc distributor. Its body is made of cast iron . Plungers are made of carburized steel with hard chrome plating.
