Eight-Digit Digital Display FDQ-XV31 Optical Fibre Amplifier (Optical Fibre Sensor)
1. High accuracy, high resolution and reliable performance
2.Response frequency up to 5kHz
3. Easy to operate, powerful, 4 detective modes
Model |
FDQ-XV31(P) |
Light Source (Luminous Wavelength) |
Red 4-Element Light Emitting Diode(625nm) |
Power Supply Voltage |
12 to 24V DC±10% |
Current Consumption |
40mA max |
Power Consumption |
480mW max. |
Control Output |
Open Collector: DC26.4V max; Load current: 100mA max; Residual Voltage: 1V max |
Response Time |
P-1: 200μs, P-2: 400μs, P-3: 1.6ms, P-4: 6.4ms |
Time Delay Function |
Disconnect delay timer/ Turn on delay timer/ single timer/ Turn on delay timer/ Turn on delay single timer, Optional; |
Timer standby time is selectable: 0.1ms to 9999ms |
|
Sensing Method |
Light intensity(Can be proceed to area Sensing, Can provide automatic sensitive tracking function) |
Display Indicator |
Operation Indicator: Red light-emitting diode/ Dual digital monitor: Dual 7-digit display, Default Value (4-digit green Light Emitting Diode indicator) |
Current value (4-digit red Light Emitting Diode indicator)Light up together |
|
Current value range: 0 to 64512, Additional gain: 0P to 999P |
If you are interested in the product, contact 2bvideo.com for more information for more information
