Compact Laser for Handheld LIBS
CNI independently developed and manufactured compact 1064nm all-solid-state passively Q-switched laser, which features a small size and stable performance, making it ideal for integration as a built-in light source in handheld LIBS applications.
This product comes in two models: the MPL-T-1064 and the EO-1064-P. The MPL-T-1064 delivers single pulse energies ranging from 1 to 100 microjoules, with pulse durations as short as 4 nanoseconds (with an optional 1.5 nanosecond setting). It operates at repetition rates between 1 and 3 kilohertz. The EO-1064-P model provides slightly lower pulse energy, from 1 to 30 microjoules, with a pulse duration of 2.6 nanoseconds and a repetition rate of 5 kilohertz. Both models are engineered to meet the demands of precision measurement, material analysis, and other high-accuracy applications.
MPL-T-1064 Features
²Frequency tunable
²Exceptional Stability
²High-quality beamz
EO-1064-P Features
²Easy integration
²High-quality beam
²Multiple power supply options (self-provided or CNI-customized)
Specifications
|
Model |
Single pulse energy |
Pulse duration |
Rep. rate |
|
MPL-T-1064 |
1~100uJ |
~4ns（1.5ns optional） |
1~3kHz |
|
EO-1064-P |
1~30uJ |
~2.6ns |
5kHz |
Dimensions
|
|
|
|
|
MPL-T-1064 LASER HEAD: 110×29×33mm3 , 0.34kg |
MPL-T-1064 POWER SUPPLY: 56×50×25mm3 , 0.07kg |
EO-1064-P |
Related Products
Optic Fiber Spectrometer
Fluorescence Spectrometer
Confocal Laser Scanning Microscopy
Raman Spectroscopy Laser
Certification
Copmpany Information
Changchun New Industries (CNI), founded in 1996, located in Changchun, CHINA, is a manufacturer of solid-state and diode laser systems. CNI possesses accountable and dependable service as well as quality products with compact design, high reliability, good performance. The products are widely used for scientific research, equipment manufacturing, biomedical experiment, precision measurement, entertainment, radar communication, material processing, process control, online detection, investigation equipment and other fields.
