What is PCB connector?
With the development of higher transmission speed and smaller size of electronic equipment, connectors also follow this trend, so chip connectors, optical fiber connectors, wired broadband connectors, and micro-pitch connectors are suitable for various portable /Connector products for wireless electronic devices are expected to become star products in the future. On the other hand, with the rapid growth of China's consumer electronics, network design, communication terminal product output and the continuous transfer of global connector production capacity to China, China has now become the world's fastest growing and largest market for connectors. PCB connector The bottom contact connector has 4 to 8 circuit specifications, its rated current and voltage are 0.3A and 50V, and can be used for 0.12mm thick FPC cables. It has a unique BackFlip clamp, which facilitates the insertion and extraction of cables in tight spaces, and has a super strong FPC cable clamping force.
1. What is a PCB connector
Its working principle is: usually the conductive pattern made of printed circuit board, Electronic Components or a combination of the two on the insulating material according to the predetermined design is called the printed circuit board. The conductive pattern that provides electrical connections between components on an insulating substrate is called a printed circuit board. In this way, the printed circuit board or printed circuit board is called PCB, also known as printed circuit board or printed circuit board.
2. PCB connector development trend
development trend:
miniaturization
Small size, light weight, small pitch, reduced height, high density/high pin number
High frequency signal/transmission
Low contact resistance, low inductance effect, good signal shielding effect, signal delay, Crosstalk... etc.
Automated operation
Reduction of station manufacturing process, Auto Pick & Place, SMT Type, product accuracy improvement, and maintenance methods
Humanized interface
User-friendly operation, fool-proof design
Low cost of use
Product standardization, flexible product and process design, delivery time reduction
3. PCB connector application
application:
PCB series connectors: used in military aviation, railway projects, industrial projects, aerospace projects, test instrument ship systems, electric sightseeing cars; UPS; communication power supplies; chargers, batteries and other products of the first choice for high-current connectors. The connector uses PBT material, which has good electronic and motor characteristics, and can be widely used in industrial needs.
All kinds of electric vehicles, electric buses, forklifts, golf carts, tourist vehicles, tractors, batteries, communication power supplies; UPS, AC and DC power supplies, EPS, inverters, high-frequency module power supplies, and high-frequency chargers Systems, suction machines, decompression machines, electric treatment beds; power supplies, material handling equipment, rechargeable battery applications, power distribution equipment, industrial equipment and other companies, and jointly developed the Anen series with the Institute of Modern Physics, Chinese Academy of Sciences Current connector products have been widely used in national large-scale electric machinery research and development projects and transportation, railway, and aerospace products.
