LPE Series Barrel Chemical Dosing Tank
Definition of PH Chlorine Flocculant Dosing Equipment
Integrated Chemical Dosing System Is Mainly Consist Of Doing Pump, Which Put Chemical Dissolving Tank, Agitation, Dosing Unit, Level Switch,Safe Valve, Check Valve,Pressure Gauge, Filter, Buffer,Pipe, Valve, Base, Ladder,Automatic Monitoring System, Electric Control System On The Public Platform. This Will Form a Module, Namely Skid-Mounted System.
The Chemical Dosage And Pressure Can Be Adjusted Based On The Industrial Process Requirements By Selecting Correct Dosing Pump. The Flow Rate Can Be Choosed From 1l/h To 8000l/h. And The Pressure Can Be Choosed From 0.1mpa To 25mpa. Based On The Different Transmission Medium, There Are Many Kinds Of Material To Choose. <Carbon Steel, Stainless Steel, Nonmetal Material (Including Pp, Pe, Pvc, Pfte)>.
Working Principle of 1000L PAC PAM Liquid Container Dosing Device
According to The Chemical Concentration, The Dosing Unit Will Prepare The Chemical Liquid In The Agitating Tank. After The Agitation, The Liquid Will Be Put Into The Dissolving Tank. By Using Metering Pump(Dosing Pump), The Solution Can Be Carried Into Dosing Point Or Required System
Anti-Acid/Alkali Plastic Chemical Dosing System Features
-High Dosing Accuracy
-Easy For Installation, Operation& Maintenance.
-High Operational Reliability.
-High Strength & High toughness.
-Good Rigidity
-Heat and Cold Resistance
-Anti-aging and Anti-UV
-Compact Structure with Small Volume
-Low Noise
-Long Service Life
(All Customized Models Are Available By Online Inquiry).
Main Technical Parameter & Model Selection
|
Model |
Capacity ( (L/h) |
Power Thickness (mm) |
Dimension (mm) |
|
LPE40 |
40 |
3.5 |
DN350*420 |
|
LPE60 |
60 |
4.0 |
DN460*480 |
|
LPE80 |
80 |
4.5 |
DN460*600 |
|
LPE100 |
100 |
5.0 |
DN460*750 |
|
LPE200 |
200 |
5.0 |
DN580*970 |
|
LPE300 |
300 |
5.0 |
DN650*1000 |
|
LPE500 |
500 |
5.0 |
DN810*1150 |
|
LPE1000 |
1000 |
6.0 |
DN1050*1350 |
|
LPE1500 |
1500 |
7.0 |
DN1210*1650 |
|
LPE2000 |
2000 |
8.0 |
DN1360*1600 |
|
LPE3000 |
3000 |
10 |
DN1600*1920 |
|
LPE5000 |
5000 |
11 |
DN1850*2380 |
|
LPE6000 |
6000 |
11 |
DN2000*2500 |
|
LPE8000 |
8000 |
11 |
DN2160*2750 |
|
LPE10000 |
10000 |
12 |
DN2300*2980 |
|
LPE15000 |
15000 |
14 |
DN2650*3400 |
|
LPE20000 |
20000 |
16 |
DN3000*3500 |
|
LPE25000 |
25000 |
20 |
DN3000*4250 |
|
LPE30000 |
30000 |
21 |
DN3400*4150 |
|
LPE40000 |
40000 |
25 |
DN3400*5170 |
|
LPE50000 |
50000 |
31 |
DN3400*6720 |
Comment: Mixer Power: 0.18/0.37/0.55/0.75/1.1/1.5/2.2/3/4/5.5KW
