1.0/1.27/2.0/2.54mm Pitch Vertical Right Angle

2 year ago
36 0
Product details
PH1.27mm Pin Header Single Row Straight Type Pin Header Connector

The  1.27 mm pitch is the most common pin header. However, other pitches, such as 1.00mm and 2.00 mm (0.079 inches), also exist for specialized applications. Number of Rows: Pin headers can have single or double rows of pins.

Overview:
Pin headers are a type of electrical connector that consists of one or more rows of metal pins or contacts molded into a plastic base. They serve as a bridge between various elements in an electronic device, enabling the distribution of power, data, and signal throughout a device.

Feature:
Technical Parameters:
Electrical characteristics
Current rating: 1.5 amps
Insulation resistance: 1000M ohms minimum
Contact resistance: Max. 20M ohms
Withstand voltage: AC500V
Contact material: copper alloy
Insulator material: PA9T, UL 94V-0 black
Mechanical properties
Durability (gold plated): 300 mating and unmating cycles
Durability (tin plated): 50 mating cycles
Insertion force: max. 2N per contact
Pull-out force: minimum 0.3N per contact
environment and processing
Operating temperature: -40°C to +105°C
LCP is suitable for: infrared reflow soldering, wave soldering, manual soldering

Application:
1.These high quality male pin header connectors are essential electronic components, connector raw materials.
2. Widely used in electronic circuit, electrical appliances, instrumentation ,PCB circuit board and so on.
3. Can be cut into the size you need.
4. Electronic factory can buy these male pin header connectors as part material, college students who major in electronic engineering or automation can use them to create high-tech products to participate in science and technology competition project.

Cable-assemblies_banner_1920x768px
Company Information:
front desk

About Us

Founded in 2008, Yuanyue Electronics Co.,Ltd is dedicated to forging a world-leading brand of customized connector and cable manufacturer. Our factory is located in Dongguan, China --- world-famous manufacturing center, and owns branch office in Taiwan and Hong Kong. We are not merely specialized in producing board-to-board, wire-to-board, wire-to-wire Connectors and Cable Assemblies, but a solution provider of customized connectors and cables as well.

Quality as survival, Reputation as development

YYE has passed ISO9001 and IATF16949 quality system certification, established a sound quality control system. Our company sticks to using imported and high-quality raw materials. Our rigorous quality team ensures that all products have passed ROHS, REACH, UL and Halogen-free certifications, and products have also obtained a number of national utility model patents.

Continuous investment in technology, productivity and efficiency

Since established,we keep increasing investment in R&D , automatic producing equipments and high precise imported testing equipments every year.Now we hold plastic mold and hardware mould more than 500 sets,automatic equipments accounts for 46% of the total equipments.

Quick Responsiveness and coordination abilities

Each client has a special project leader and a professional engineer following your items and instant feedback.we even independently developed a set of automatic equipment for our customers, assisting customers in reducing costs and decreasing lead-time.



YYe Company History


Our product lines include a wide range of connectors, terminals and cable assemblies, which are widely used in communications, home appliances, medical, security, new energy, industrial control and other fields.

The main products include: OEM/ODM various cable assemblies, wire-to-board connectors, automotive connectors, board-to-board connectors, I/O connectors, customized connectors, etc.

The above 1.00mm pin header are only some of our connectors and accessories
, if you don't find the parts you need, please feel free to send us an inquiry for more solutions.



DSC_5167



Shipment and Payment:

FAQ:
Are you trading company or manufacturer?
A: We are factory with over 17 years experience in connector and wire industry.

Delivery time?
A: Generally 5-7 days for standard products within quantity of 10,000 pcs.

Do you provide samples? is it free or charged?
A: Free samples are always available for testing or quality evaluation purpose

What is your terms of payment?
A: Payment terms are flexible, T/T, Paypal, L/C, D/A, D/P, Westem Union, metc.
