Product details

3T Electric Counter-balanced Forklift with Full-closed Cabin

Counter balanced forklift is one of the most widely-used type of forklift machines as electric pallet jack rider. Differs from electric stacker, reach stacker and other material handling equipment, counterbalanced forklift is more stable and has better performance on tough terrains. It can take duty both indoors and outdoors, but need more channel width than reach truck forklift and VNA trucks. The electric power can also save more daily cost for a long and reliable performance compared with diesel one.

Main Features

1. Pedal distributing of best angle
The electric 4 wheel counterbalance forklift truck is equipped with a surrounding type seat which is

2. Larger gradeabilityan ergonomic design. It allows for waist adjustment and helps the operator maintain proper driving posture.
The gradeability can be up to 15%. The climbing speed can be up to 4km/h even when fully loaded.

3. Cruising ability
The durable battery and improved performance and efficiency allocation can greatly increase the cruising ability of the forklift truck which means that the working period can be increased by 10%.

4. Faster moving speed
Fully loaded speed can be up to 14km/h.

5. High intensity overhead guard
The overhead guard is made of an irregular polygonal extruded material which delivers good compressive resistance and impact resistance in order to ensure the intensity of the overhead guard. Meanwhile, it can protect the driver from being hurt by falling materials.

6. High position steering node
The lateral moving is highly stable to reduce rollover.

7. Superior noise reduction technology
The reasonable distribution and design of the noise reduction technology effectively quiets the forklift.

8. Fully AC system
This truck has superior performance control. The motor is always maintenance free.

9. The battery can be loaded and unloaded at the side so that the time of changing battery can be effectively reduced and the working efficiency can be improved, especially for the working condition with higher working intensity. There are optional batteries such as FAAM and GS.

10. 70% of the truck adopts molded components which can ensure the reliability of the whole truck.

Technical Data

	Identification
1	Model				FE30
2	Power supply				Battery
3	Load capacity			kg	3000
4	Load center			mm	500
5	Self weight			kg	5100
	Tyres and chasis
6	Tyres				Solid tyre
7	Wheels quantity X=Drive（Front/back）				2X/2
8	Front tyre size				28×9-15-12PR
9	Rear tyre size				18×7-8-14PR
10	Front gauge		W3	mm	1000
11	Rear gauge		W4	mm	980
12	Wheelbase		L1	mm	1700
	Dimension
13	Lifting height		h3	mm	3000
14	Fork size	L×w×t	L4×W×T	mm	1070×125×45
15	Mast tilting	Front/Rear	α/β	。	6/12
16	Mast closed height		H1	mm	2115
17	Free lift height		H3	mm	125
18	Max extended height		H2	mm	4175
19	Rack height（From the fork surface）		H6	mm	1140
20	Adjustable fork width		W5	mm	250-1100
21	Overall length （Without fork/with fork）		L'/L	mm	2610/3680
22	Overall width（Chasis）		W1	mm	1230
23	Overhead guard height		H4	mm	2250
24	Distandce between the seat and overhead guard		H7	mm	1020
25	Front overhang		L2	mm	480
26	Back overhang		L3	mm	430
27	Min turning radidus		r	mm	2350
28	Min Ground clearance （from the bottom mast）		H5	mm	140
29	Aisle width for moving min		Ra	mm	2425
30	Working aisle width,min		RASA	mm	4070
	Performance
31	Max driving speed（Loaded/unloaded）			km/h	13/14
32	Max lifting speed（Loaded/unloaded）			mm/s	300/380
33	Max lower speed（Loaded/unloaded）			mm/s	≤600/≥300
34	Gradeability（Loaded）			%	15
	Electric
35	Battery(Voltage/Capacity）			V/Ah	80/500
36	Battery box	Length×Width×Height		mm	1015×690×815
37	Motor rating	Driving		Kw	15
38	Motor rating	Lifting		Kw	12
40	Controller type				AC
	Others
41	Hydraulic working pressure			Mpa	17.5

Product Display

counterbalanced forklift with closed cabin
