Downhole Tool Rubber Tubing Centralizer
Rigid centralizers series.Including standard bow type,rigid bar type and spiral blade type,designed for use in highly deviated and horizonal well.
Stamped Solid Centralizer is designed to provide a positive stand off the casing.
The blades design can reduce minimum friction when running a casing duo to the smooth profile.
Increase flow-by area to optimize mud displacement in vertical,inclined,and horizontal wells.
Available in straight or spiral blades, these blades are mechanically formed rather than welded onto the centralizer body.
Different sizes are available
Cementing Accessories, Casing Centralizer, Pressure Vessels, Cementing Tool, Pumping Units, Centralizers, Accessories, Sucker Rod
Downhole Tool Rubber Tubing Centralizer Specification
| Specification |
casing size (mm) |
Outer Diameter (mm) |
Hole Size (mm) |
Inner Diameter (mm) |
| 4-1/2"×6" | 114 | 146 | 152 | 118 |
| 5"×6 5/8" | 127 | 162 | 168 | 131 |
| 5-1/2″×8-1/2″ | 140 | 210 | 216 | 142 |
| 6-5/8″×8-1/2″ | 168 | 210 | 216 | 172 |
| 7″×8-1/2″ | 178 | 210 | 216 | 182 |
| 7"× 9-1/2" | 178 | 235 | 241 | 182 |
| 9-5/8″×12-1/4″ | 244 | 305 | 311 | 249 |
| 13-3/8″×17-1/2" | 340 | 439 | 445 | 344 |
If you are interested in the product, contact 2bvideo.com for more information for more information
