PEEK Product is a kind of heat-resistant, high performance thermoplastic special engineering plastics. It has good mechanical properties and chemical resistance, abrasion resistance, and hydrolysis resistance properties etc.; it has a light proportion and self-lubricating properties.
Property
Item No.
Unit
PEEK-1000
PEEK-CA30
PEEK-GF30
1
Density
g/cm3
1.31
1.41
1.51
2
Water absorption(23℃ in air)
％
0.20
0.14
0.14
3
Tensile strength
MPa
110
130
90
4
Tensile strain at break
％
20
5
5
5
Compressive stress(at 2%nominal strain)
MPa
57
97
81
6
Charpy impact strength (unnotched)
KJ/m2
No break
35
35
7
Charpy impact strength (notched)
KJ/m2
3.5
4
4
8
Tensile modulus of elasticity
MPa
4400
7700
6300
9
Ball indentation hardness
N2
230
325
270
10
Rockwell hardness
--
M105
M102
M99
Heat-resistance
PEEK has a higher glass transition temperature and melting point (334℃). It is one of the reasons that it can be a reliable application in the requirement of the heat. Its heat load variable-temperature can be 316℃, continuous
use temperature is 260℃.
Mechanical Properties
PEEK is the plastic that strikes a balance between toughness and rigidity. Especially, it has an excellent fatigue resistance against alternating stress that is the most talented of all plastics, and it can be comparable with alloys.
Self-lubricating
PEEK has outstanding sliding characteristics in all plastics; it is suitable for stringent requirements for low coefficient of friction and resistance to friction used. Especially, the self-lubricating properties of PEEK will be better if it is modified by carbon fiber and graphite mixed in the proportion of each of them.
Chemical Resistance
PEEK has excellent chemical resistance. In ordinary chemicals, it can be dissolved or damaged only by concentrated sulfuric acid; its corrosion resistance is similar to those of steel and nickel.
