ASTM A588 A633 Low Alloy Steel Plate
ASTM A588 is the standard specification for high-strength, low-alloy structural steel with a minimum yield strength of up to 50 ksi and resistance to atmospheric corrosion for applications where strength and durability are required. The required ASTM G101 corrosion resistance index must be ≥ 6.0. Besides typical applications in welded bridges and buildings, this specification is also widely used in passenger cars.
ASTM A633 is the standard specification for normalized high-strength low-alloy structural steel sheets where superior low-temperature toughness is required. Grade C is available in thicknesses up to 4 inches, and Grade E is available in thicknesses up to 6 inches. Typical applications include power poles in slab form, offshore platforms, construction equipment frames, electric excavator bucket handles, and suspension components.
A588 steel plate Mechanical property:
A633 steel plate mechanical property:
Steel grade
Styles
Tensile strength, ksi [MPa]
Yield point, min, ksi [MPa]
Elongation in 8 in. [200 mm], min, %
Elongation in 2 in. [50 mm], min, %
A588 Grade A
Steel angles
70 [485]
50 [345]
18
21
| Carbon, max | 0.18 | 0.20 | 0.20 | 0.22 |
| Manganese: | ||||
| 1½ in. [40 mm] and under in thickness | 1.00-1.35 | 1.15-1.50B | 0.70-1.35 | 1.15-1.50 |
| Over 1½ in. to 4 in. [40 to 100 mm], incl | 1.00-1.35 | 1.15-1.50B | 1.00-1.60 | 1.15-1.50 |
| Over 4 in. to 6 in. [100 to 150 mm], incl | C | C | C | 1.15-1.50 |
| Phosphorus, max | 0.030 | 0.030 | 0.030 | 0.030 |
| Sulfur, max | 0.030 | 0.030 | 0.030 | 0.030 |
| Silicon | 0.15-0.50 | 0.15-0.50 | 0.15-0.50 | 0.15-0.50 |
| Vanadium | – | – | – | 0.04-0.11 |
| Columbium | 0.05 max | 0.01-0.05 | – | D |
| Nitrogen, max | – | – | – | 0.03 |
| Copper, max | – | – | 0.35 | – |
| Nickel, max | – | – | 0.25 | – |
| Chromium, max | – | – | 0.25 | – |
| Molybdenum, max | – | – | 0.08 | – |
We can provide customized services. We can customize ASTM A588 A633 Low Alloy Steel Plate, Alloy 400 Steel Plate, A537 Pressure Vessel Plate and other products according to your needs. If you have any needs, please contact us.
