MPI have two division, electronics design & assembly house and metal stamping & CNC chop.
In Electronics shop we provide our professional skills on power electronics design and manufacture. From A to Z, we can help you translate your idea into real products.
The DT10 series offer 10 watts of output power form a 2.0" × 1.0" × 0.4" package.
DT10 series have 2:1 wide input voltage of 9.5 ~ 18, 18 ~ 36 and 36 ~ 72Vdc.
The DT10 series are isolated, forward topology DC-DC converters
DT10series DC/DC converter
Features:
Applications:
Input Specification
|
Model number |
Typ. |
Input range |
Unit |
|
DT10-12SXX |
12 |
9.5 ~ 18 |
Vdc |
|
DT10-24SXX |
24 |
18 ~ 36 |
|
|
DT10-48SXX |
48 |
36 ~ 72 |
Output Specification
|
Model number |
Voltage |
Unit |
current |
Unit |
|
DT10-XXS03 |
3.3 |
Vdc |
2500 |
mA |
|
DT10-XXS05 |
5 |
2000 |
||
|
DT10-XXS09 |
9 |
1100 |
||
|
DT10-XXS12 |
12 |
840 |
||
|
DT10-XXS15 |
15 |
670 |
||
|
DT10-XXS24 |
24 |
420 |
General Specification
|
Output power |
10 Watts Max. |
|
|
Minimum load |
0 mA |
|
|
Isolation voltage |
1500 Vdc Min. |
|
|
Isolation resistance |
100M ohm Min. |
|
|
Isolation capacitance |
1000 pF |
|
|
Switching Frequency |
300 KHz Typ. |
|
|
Case material |
Copper |
|
|
Dimensions |
2.0 ×1.0 × 0.4 inch |
|
|
50.8 ×25.4 × 10.2 mm |
||
|
Weight |
31g |
|
|
Idle current |
20 mA Typ. |
|
|
Load regulation (no load to full load at nominal input) |
±1% |
|
|
Over voltage protection clamp by zener diode |
Output voltage |
Zener diode |
|
3.3V |
3.9V |
|
|
5V |
6.2V |
|
|
9V |
11V |
|
|
12V |
15V |
|
|
15V |
18V |
|
|
24V |
27V |
|
|
Over load protection (nominal input) |
150% Max. |
|
|
Environment |
Working Temp. |
-25oC ~ +70oC |
|
Working Humidity |
0% ~ 95% |
|
|
Storage Temp. |
-40oC ~ +105oC |
|
|
Storage Humidity |
0% ~ 95% |
|
|
MTBF (Ta = 25oC) |
50K hours |
|
| A/D Converter | DC/DC Converter | LED Driver & Other |
| Access Control | Audio | LED Nail Lamp | Other |
| Power Supply Components | Heat sink | Heat sink & Machining | CNC Machining | Audio | Cable |
Applications
Our Metal shop provide professional stamping service which include creating mold, stamping and surface treatment. The implementation of CNC machine provide high precision machining parts and machining service to our customer.
Over 20 years experience on doing business with US and EU customers. We can understand what you need and what you concern.
We are able to reply to customer within 24 hours, which can let you speed up your decision and solve your problem immediately.
If you are interested in the product, contact 2bvideo.com for more information for more information
