| XCMG 18m GTBZ18A1 Telescopic Boom Lift | ||
|
Item
|
Unit
|
Parameter
|
|
Overall length
|
mm
|
9080
|
|
Overall width
|
mm
|
2490
|
|
Overall height
|
mm
|
2680
|
|
Wheelbase
|
mm
|
2500
|
|
Maximum working height
|
m
|
20.3
|
|
Maximum platform height
|
m
|
18.6
|
|
Maximum working range
|
m
|
11.9
|
|
Maximum load weight
|
kg
|
230
|
|
No.1 arm luffing range
|
°
|
0 ~ +70
|
|
No.2 arm luffing range
|
°
|
0 ~ +75
|
|
Crank arm luffing range
|
°
|
-65 ~ 70
|
|
The swing angle of the rotary table
|
°
|
360
|
|
Maximum tail wagging
|
mm
|
0
|
|
Platform size
|
mm
|
1830×760×1150
|
|
The swing angle of the platform
|
°
|
180
|
|
Machine weight
|
kg
|
10600
|
|
Maximum travelling speed
|
km/h
|
6.0
|
|
Minimum turning radius
|
m
|
6.0
|
|
Minimum ground clearance
|
mm
|
230
|
|
Maximum gradeability
|
%
|
45
|
|
Tyre size
|
|
355/55D625
|
|
Motor model
|
|
Perkins 404D-22
Deutz D2011L03i |
|
Rated power of motor
|
kW/(r/min)
|
38KW/3000rpm,
36.3 KW/2800rpm |
