The very high frequency directional antenna adopts a three-unit Yagi antenna. The antenna body consists of an active oscillator, a director, a reflector, a parallel double line, etc. It is composed of parts. The antenna is elevated horizontally or vertically through the mast. The antenna has technical characteristics such as directional radiation, high gain, small standing wave ratio, and large power capacity. The antenna structure has strong wind resistance, stable performance, reliable structure, and easy installation and erection.
The product is suitable for erection on the ground or on the roof.
Main technical parameters
Ø Frequency: 118MHz ~ 137MHz;
Ø Input impedance: 50Ω;
Ø Gain: 6dBi;
Ø VSWR: ≤1.5;
Ø Polarization: vertical/horizontal polarization;
Ø Directional pattern: H plane beam Width is 120°, E-plane beam width is 64°
Ø Power: 1000W;
Ø Weight: ≤7kg;
Ø Dimensions: The length of the reflector is 1360mm, the length of the active vibrator is 1268mm, and the length of the director is 1000mm.
Ø RF interface: N-50K
