ASTM A106 A53 Gr.B Seamless Steel Pipe

13 month ago

24 0

SHANDONG HUITONG STEEL CO.,LTD

 3 year year

Product details

Boiler Alloy Steel Pipe

ASTM A213 Alloy Tubes

ASTM A213 Alloy Tubes are a series of seamless ferritic and austenitic alloy-steel tubes that are designed for use in high-temperature and corrosive environments.

ASTM A213 Alloy Tubes are commonly used in industries such as power generation, petrochemicals, pharmaceuticals, and chemical processing. They offer excellent resistance to oxidation and corrosion at high temperatures and pressures, making them ideal for use in severe environments.

The tubes undergo various tests, including hydrostatic testing, non-destructive testing, and tensile testing to ensure they meet the required specifications. The ASTM A213 standard covers a wide range of sizes and dimensions, allowing for versatility in applications.

Some key features and benefits of ASTM A213 Alloy Tubes include:

High-temperature resistance: The alloy steel used in these tubes offers excellent resistance to high temperatures and thermal shock.
Corrosion resistance: These tubes offer excellent resistance to corrosion and oxidation even in harsh environments.
Durability: The tubes are designed to withstand high pressure and temperature conditions, making them durable and reliable.
Versatility: ASTM A213 Alloy Tubes are widely available in various sizes, shapes, and dimensions enabling their usage in different applications.
Easy fabrication: These tubes can be fabricated easily, meaning that production costs are kept down.

In conclusion, ASTM A213 Alloy Tubes are a series of seamless ferritic and austenitic alloy-steel tubes that are designed for use in high-temperature and corrosive environments. They offer several key features and benefits such as high-temperature resistance, corrosion resistance, durability, versatility, and easy fabrication.

ASTM A213 Alloy Tubes material could be in alloy steel and stainless steel, and manufactured in seamless of hot rolled or cold drawn. So this pipe usually used in very important places and the price is much higher than normal carbon pipes.

Sunny Steel Supply stocks a full range of the following ASTM A213 grades:

Main grades: ASTM A213 T5, T5b, T9, T11, T91 and T22

Size range:

NPS 1/4'' to NPS 24''
Wall Thickness - Schedules 40 through 160, STD, XS, XXS.
Unscheduled heavy wall pipe thicknesses available up to 4 inches.

ASTM A213 T12 ASTM A213 T11

ASTM A213 T5

ASTM A213M-09 Material Comparison Tables

Grade	UNS Designation	C	Mn	P	S	Si	Vanadium	Boron	Niobium	Nitrogen	Aluminum	Tungsten
T2	K11547	0.10–0.20	0.30–0.61	0.025	0.025B	0.10–0.30	...	...	...	...	...	...
T5	K41545	0.15	0.30–0.60	0.025	0.025	0.5	...	...	...	...	...	...
T5b	K51545	0.15	0.30–0.60	0.025	0.025	1.00–2.00	...	...	...	...	...	...
T5c	K41245	0.12	0.30–0.60	0.025	0.025	0.5	...	...	...	...	...	...
T9	K90941	0.15	0.30–0.60	0.025	0.025	0.25–1.00	...	...	...	...	...	...
T11	K11597	0.05–0.15	0.30–0.60	0.025	0.025	0.50–1.00	...	...	...	...	...	...
T12	K11562	0.05–0.15	0.30–0.61	0.025	0.025B	0.5	...	...	...	...	...	...
T17	K12047	0.15–0.25	0.30–0.61	0.025	0.025	0.15–0.35	0.15	...	...	...	...	...
T21	K31545	0.05–0.15	0.30–0.60	0.025	0.025	0.50–1.00	...	...	...	...	...	...
T22	K21590	0.05–0.15	0.30–0.60	0.025	0.025	0.5	...	...	...	...	...	...
T23	K40712	0.04–0.10	0.10–0.60	0.03	0.01	0.5	0.20–0.30	0.0010–0.006	0.02–0.08	0.015	0.03	1.45–1.75
T24	K30736	0.05–0.10	0.30–0.70	0.02	0.01	0.15–0.45	0.20–0.30	0.0015–0.007	...	0.012	0.02	...
T36	K21001	0.10–0.17	0.80–1.20	0.03	0.025	0.25–0.50	0.02	...	0.015–0.045	0.02	0.05	...
T91	K90901	0.07–0.14	0.30–0.60	0.02	0.01	0.20–0.50	0.18–0.25	...	0.06–0.10	0.030–0.07	0.02	...
T92	K92460	0.07–0.13	0.30–0.60	0.02	0.01	0.5	0.15–0.25	0.001–0.006	0.04–0.09	0.030–0.07	0.02	1.5–2.00
T122	K91271	0.07–0.14	0.7	0.02	0.01	0.5	0.15–0.30	0.0005–0.005	0.04–0.10	0.040–	0.02	1.50–2.50
T911	K91061	0.09–0.13	0.30–0.60	0.02	0.01	0.10–0.50	0.18–0.25	0.0003–0.006	0.06–0.10	0.040–0.09	0.02	0.90–1.10

ASTM A213M-09 Mechanical properties

Grade	Tensile strength (Mpa)	Yield point(Mpa) not less than	Elongation(%) not less than	Impact(J) not less than	Hardness not less than
A213 T2/SA213 T2	≥415	205		"	85HRB
A213 T11/SA213 T11	≥415	205		"	85HRB
A213 T22/SA213 T22	≥415	205		"	85HRB
A213 T23/SA213 T23	≥510	400	20	"	97HRB
A213 T24/SA213 T24	≥585	415	20	"	25HRB
A213 T91/SA213 T91	≥585	415	20	"	25HRB
A213 T911/SA213 T911	≥620	440	20	"	25HRB
A213 T22/SA213 T92	≥620	440	20	"	25HRB
A213 T122/SA213 T122	≥620	400	20		25HRB
TP304H	≥515	205	35		90HRB
TP316H	≥515	205	35		90HRB
TP321H	≥515	205	35		90HRB
TP347H	≥515	205	35		90HRB
S30432	≥590	235	35		95HRB
TP310HCbN	≥655	295	30		100HRB
