Product details

ASME SA588 corten steel plate

ASME SA588 corten steel plate or Sa588 Weathering Resistant Steel is a kind of high-strength low-alloy structurel steel, with standard of ASME. SA588 is divided into four grade: gradeA/B/C/K.

Product application:
SA588 plate is mainly used for use in welded bridges and buildings

Chemial content:

Item	C (max)	Mn	P (max)	S (max)	Si	Ni	Cr	Mo	Cu	V
SA588 Grade A	0.19	0.8-1.25	0.04	0.05	0.3-0.65	0.04	0.4-0.65	/	0.25-0.5	0.02-0.1
SA588 Grade B	0.19	0.8-1.25	0.04	0.05	0.3-0.65	0.40	0.4-0.65	/	0.25-0.4	0.02-0.1
SA588 Grade C	0.15	0.8-1.25	0.04	0.05	0.15-0.5	0.25-0.50	0.4-0.65	/	0.20-0.5	0.01-0.1
SA588 Grade K	0.17	0.8-1.25	0.04	0.05	0.25-0.65	0.25-0.50	0.4-0.65	0.1	0.3-0.5	0.005-0.05

Mechanical properties:

Grade	Thickness	Yield Strength Mpa (min)	Tensile Strength Mpa	Elongation % in 200mm	Elongation % in 50mm
SA588 Grade A	less 100mm	345	485	18	21
	100-125mm	315	460	18	21
	125-200mm	290	435	18	21
SA588 Grade B	less 100mm	345	485	18	21
	100-125mm	315	460	18	21
	125-200mm	290	435	18	21
SA588 Grade C	less 100mm	345	485	18	21
	100-125mm	315	460	18	21
	125-200mm	290	435	18	21
SA588 Grade K	less 100mm	345	485	18	21
	100-125mm	315	460	18	21
	125-200mm	290	435	18	21

Cooperative partner:

cooperative

Except SA588 steel plate, Houming also provide A242/Q295 corten steel and ship steel plate, pressure steel plate, carbon steel plate etc.
