Warehouse transportation three-wheeled electric vehicle
The Household Transportation Vehicle motor has high power and adopts a new generation of brushless and toothless high-speed motors. The Electric Cargo Tricycle motor utilizes a powerful magnetic field to generate kinetic energy, reduce operating noise, start faster, and eliminate weak load capacity. Free electric circulation uses electrophoretic coating, which is durable and revitalized. The surface treatment of electric goods circulation adopts a new technology that uses metal electrophoretic coating particles to achieve better glossiness. Agricultural recycling uses natural paint technology to prevent rusting. The carriage is equipped with integrated stamping plates, reinforced guardrails, spacious storage compartments, and sturdy guardrails, making it easy to handle goods. The Electric Passenger Tricycle is equipped with thickened spring hydraulic shock absorbers, which have good shock absorption effect and stronger load-bearing capacity.
Specification
| Technical parameter sof electric tricycle | Number | Item | specification |
| Finished vehicle body | 1 | Wholecar | |
| 2 | Climb slope | ≤35° | |
| 3 | Height off ground | ≤200mm | |
| 4 | Bearing weight | ≥500kg | |
| 5 | Wheel track | 900mm | |
| 6 | Wheel base | 2000mm | |
| 7 | Battery position | Frame battery box | |
| 8 | Boundary dimension | 3000*1000*1550mm | |
| 9 | Maximum speed | ≤26Km/h | |
| 10 | Astern speed | ≤12Km/h | |
| 11 | endurance mileage | ≥50Km/h | |
| 12 | Tyre type | Front:375-12Rear:400-12 | |
| 13 | configuration | integrated 160 gear shifting，37 shock absorption，two beams, drum brake | |
| Carriage | 1 | material | 1.1 mm iron plate electro phoretic baking paint |
| 2 | Carriage size | 1500*1000mm | |
| Recharge battery | 1 | Battery type | maintenance-free |
| 2 | Battery capacity | Selective configuration | |
| 3 | Battery voltage | 60V | |
| motor | 1 | Output power | 800W |
| 2 | Motorvoltage | 60V | |
| controller | 1 | Specification requirements | 18 tubes double row |
| 2 | Rated voltage | 60V | |
| Rearview mirror | 1 | type | specific |
If you are interested in the product, contact 2bvideo.com for more information for more information
