1045 S45C C45 cold drawn steel round bar
1045 S45C C45 steel material is a medium carbon steel grade with good mechanical properties for a various applications. 1045 S45C C45 steel bar is usually used in many industries like automotive, agriculture, construction and motorcycle.
Specification of 1045 S45C C45 steel bar we supply:
Sizes
Wide range from 6mm to 100mm
Tolerances
Precision to h9, h10, h11
Roundness
75% of diameter tolerance
Straightness
Good straightness to 0.5mm/m
Surface roughness
Smooth to 1.6um
Mechanical properties
Yield strength and tensile strength can be improved
Machining
Suitable for machining and welding
1. 1045 S45C C45 steel equivalent material:
|
GB |
ASTM/SAE/AISI |
DIN |
SCM |
AS /NZS1444 |
|
45# |
Aisi 1045 / sae 1045 / astm 1045 |
C45 CK45 |
S45C |
AS 1045 |
2. 1045 S45C C45 steel chemical composition:
|
Material |
Chemical Composition % |
||||||
|
|
C |
Si |
Mn |
S |
P |
Cr |
Mo |
|
1045 |
0.42-0.48 |
0.15-0.35 |
0.60-0.90 |
0.035 max |
0.035 max |
0.035 max |
0.035 max |
3. 1045 S45C C45 normalized steel mechanical properties:
|
Mechanical Properties |
||||
|
Yield Strength (MPa) |
Tensile Strength (MPa) |
Elongation |
Reduction of area |
Hardness |
|
400 min |
640 min |
222% min |
54% min |
32HRC max |
|
Gears |
Pins |
Rams |
|
Shafts |
rollers |
sockets |
|
axles |
spindles |
worms |
|
bolts |
ratchets |
Light gears |
|
studs |
crankshafts |
Guide rods |
|
Connecting rods |
Torsion bars |
Hydraulic clamps |
Except cold drawn steel Round Bar, we can also produce other shapes cold drawn steel bar such as Cold Drawn Round Bar, Cold Drawn Steel Square Bar, cold drawn flat bar and cold drawn Hexagonal Steel Bar. Except cold drawn steel bar, we can also do further processing for Turned Steel Bar, polished steel bar and centerless ground bar.
