Product details

The plastic vacuum calibration tank—standard equipment on every PVC Profile Production Line and WPC Profile Extrusion Machine—offers precise up-down / left-right movement that can be manually adjusted through the threaded hand-wheels.

Dual-circuit water supply system for independent spray and vacuum zones.
Variable-frequency vacuum auto-control system that self-tunes to the profile puller speed of the PVC Profile Production Line or WPC Profile Extrusion Machine.
Water-temperature control: 0–30 °C mechanical regulating valve keeps the cooling rate ideal for rigid PVC or wood-plastic composites.
High-level drainage: electromagnetic level gauge + pneumatic angle-seat valve.
Low-level make-up: stainless-steel float maintains minimum bath level.
Clamping quick-connect ABS nozzles deliver intensive, uniform spray cooling—critical for tight dimensional tolerance on any PVC Profile Production Line or WPC Profile Extrusion Machine.
Large PE “European-cosmetics” filter cartridge for high-flow, fine-particle removal.
Combined vacuum seal: spray flange + natural-rubber O-ring.
Six half-moon tray sets (or nylon rollers) support the profile and preserve roundness / straightness.
Tempered-glass door cover with convex rubber seal for safe, drip-free viewing.
Manual fill & drain ports plus high-capacity gas-water separator.
In-line flow meter lets operators fine-tune water distribution to each rubber calibration sleeve.

At The Same Time, Our Workshop Also Produces Plastic pipe Coiler/Pipe Winding Machine, plastic pipe Hauling Machine, And Plastic Crusher To Provide You with One-Stop Service. We Can Help You Combine the Machines You Need to Improve Your Efficiency. We Will Also Provide Unified After-Sales Service.

Pipe Diameter	16-63	20-110	50-160	90-250	90-315	110-450	250-630		400-800		500-1000

Tank Length(MM)	9000	9000	9000	9000	9000	9000	2400	9000	2400	9000	2400	10000

Tank Thickness(MM)	3	3	3	4	4	5	6	6	6	6	8	8

Tank Side Board Thickness(MM)	8	8	8	10	10	12	12	12	14	14	16	16

Vacuum Pump Power(KW)	1.5+2.2	2.2+2.2	2.2 +3	3+4	4+5.5	5.5+5.5	5.5	5.5*2	5.5	5.5*2	7.5	5.5*3

Water Pump Power(KW)	3+4	3+4	4+5.5	4+5.5	5.5+7.5	7.5+7.5	7.5	7.5*2	7.5	7.5*2	7.5	7.5*3

Spray Cooling Pipe	4	4	4	4	6	8	10	10	12	12	16	16

Open Lid Quantity	7	7	7	7	7	7	2	7	2	7	2	7
