Application scope: As a hydraulic and pneumatic actuator, cylinders are widely used in automation control fields such as machinery, engineering equipment, transportation equipment, medical equipment, and automotive production lines based on their working principles, specifications, and models. And with the rapid development of industrial production, it will give full play to its newness, economy and progressiveness, and it will have a broad development prospect in many applicable areas.
Parameter description: Cylinder diameter mm: 12, 16, 20, 25, 32, 40, 50, 63, 80, 100 Fluid: Air Action type: Double action single action: Spring press back/Spring press out Guaranteed pressure resistance: 1.5MPa Maximum operating pressure: 1.0MPa Environment and fluid temperature: 5-60 ° C Rod end thread: Internal thread (standard), external thread (optional) Buffer: No travel tolerance: Upper deviation 1.0, lower deviation 0 Lubrication: No installation required: Through hole (standard), internal threads at both ends (optional) Cylinder diameter is (12, 16, 20, 25) mm Pipe diameter: M5 * 0.8 Cylinder diameter is (32, 40) mm Pipe diameter: 1/8 Cylinder diameter is (50) mm 63) mm pipe diameter: 1/4 cylinder diameter is (80, 100) mm pipe diameter: 3/8
Product Features
1,Manufactured by our enterprise;Air Cylinder Tube.
2,Riveted structure is adopted to connect the cylinder body and back cover, and piston and piston rod to make it compact and reliable;
3,The inner diameter of the body is treated with rolling followed by the treatment of hard anodizing, forming an excellent abrasion resistance and durability;Pneumatic Cylinder Barrel.
4,The seal of piston adopts heterogeneous two-way seal structure. It has compact dimension and the function of oil reservation;
5,Compact structure can effectively save installation space;Air Cylinder Barrel.
6,There are magnetic switch slots around the cylinder body, which is convenient to install sensor switch;
7,Mounting accessories with various specifications are optional.SMC Pneumatic Cylinder Tubing.
