Main Applications：
In the large-scale production process of whole house customization, indoor wooden doors, and panel furniture, the dimensional regularity of the panels and door leaves directly determines the quality of the finished products for subsequent edge sealing, assembly, and installation. Traditional push table saws have accumulated large errors and require a lot of manual labor for repeated flipping and cutting, making it difficult to meet high standard production needs. As a specialized precision cutting equipment, the core function of a four sided saw is to complete the precise cutting process of door leaves and various types of boards.
This four sided saw adopts a vertical and horizontal combination saw head structure, with a workpiece through type automatic conveying and positioning, without the need for manual flipping and calibration. It can synchronously cut the four edges of the workpiece in a single feeding, accurately completing the three major processes of length and width sizing, right angle squaring, and burr trimming. Regarding the subdivision of processing objects, when processing solid wood doors, composite set doors, and unpainted interior door panels, the diagonal and length width tolerances can be strictly controlled to ensure that each batch of door panels has uniform dimensions and is installed tightly and seamlessly; When processing furniture boards such as density board, particle board, multi-layer board, ecological board, and particleboard, it is necessary to use a mother child anti chipping saw blade to ensure a smooth and burr free cutting surface, greatly reducing the amount of rework and polishing work in the later stage.
Compared to traditional multi pass cutting techniques, the four sided saw has a higher degree of automation, with a servo positioning system locking the cutting accuracy. A single person can complete the entire process of feeding, processing, and discharging, and the processing efficiency is more than three times that of ordinary single saw equipment. It can adapt to large-scale standardized wooden door factories and meet the flexible production needs of multi size customized furniture workshops. The body is equipped with a stable welded frame and a dust-proof waste recycling structure. It is not easy to shake during long-term continuous operation, and the accuracy is long-lasting and stable. Long term use can effectively reduce board loss, labor costs, and defect rates. It is an indispensable core precision cutting supporting equipment in wooden door production lines and panel furniture production lines.
If the workshop is facing difficulties such as door leaf cutting size deviation and low efficiency of board trimming, the four sided saw can customize machine parameters according to the maximum processing width of the door leaf and the thickness of the board, and adapt to the production line layout of different scale factories.
Main features:
1、Ball screw transmission ensures sawing stability and keep the accuracy;
2、Worktable surface with sponge,suction/blow avoid board surface scratches;
3、PC control system could customize the software and MES connect solutions;
4、Center align the core layer to ensure the material cutting from both long sides evenly;
5、Through-type feed,allow in/out same time and flexible connect with production lines;
6、Automatic worktable satisfy frequent door size changes without manual adjustment;
7、Main & score saw prevents edge broken,inprove product quality(Crush blade optional);
8、Optional 5° tilt beveled sawing;
9、Bar code scanner for optional input door size,reduces human error and more efficiency.
The centering system ensure that the remaining of Main & Scoring saw design to ensures cutting without edge
both siades are equal,evenly cutting two edges. broken and get high quality sawing results.
Adjustment positioning system,to ensure workpiece With PC control system,graphical operation is easier
length direction cutting size adjustable,to meet the Optional:Barcode scanner,more efficiency.
different products needed.
