The performance of an AC solenoid air pump can indeed be judged from aspects such as speed, power, air volume and noise.
1. Speed: Generally speaking, the higher the speed of the AC diaphragm air pump, the greater the power it generates. This is because the speed of the air pump is directly related to the moving speed of the piston or blade inside it. The faster the moving speed, the greater the air pressure or flow generated.
2. Power: Power refers to the energy generated by the AC solenoid pump per unit time. Generally speaking, the more powerful an air pump is, the greater its ability to generate air pressure or flow.
3. Air volume: Air volume is one of the important indicators to measure the performance of the air pump. It represents the volume of gas that the air pump can deliver per unit time. Generally speaking, an air pump with a larger air volume will have a wider range of applications.
4. Noise: The noise of the solenoid air pump is also one of the important indicators to measure its performance. Although high-speed and high-power air pumps will produce greater air pressure and flow, they will also bring greater noise. Excessive noise will not only affect people's lives and work, but may also cause damage to the equipment itself.
Therefore, when choosing an air pump, you need to comprehensively consider all the above factors based on actual needs to choose the air pump that best suits your usage conditions.
Do solenoid pump need air?
The AC solenoid air pump requires air because it is an air compressor driven by electromagnetic force. Its working principle is to control the inflow and outflow of compressed air by turning on and off the electromagnet. When the electromagnet is powered on, it will attract the piston in the air pump to reciprocate, thereby compressing and discharging the air; when the electromagnet is powered off, the piston returns to its original position under the action of the spring, preparing for the next compression. Therefore, AC electromagnetic air pumps require air as the operating medium
Technical Specification
| Product Model | DHB15-24V |
| Voltage | AC 240V |
| Power |
<10W |
| Air flow rate |
>15L/Min |
| Media | Air |
| Life cycle |
>20,000 cycles(work for 30min and stop for 10min as a cycle) |
|
Working temperature |
5℃~40℃ |
|
Weight |
65g |
| Pressure | 26-36KPA |
| Application | Mainly used for varicose veins treatment and lymphatic circulation therapy. |
Dimension Drawing
Application
Does AC solenoid pump has polarity?
AC solenoid pump generally has no polarity. AC solenoid pumps are driven using alternating current (AC), which means the current changes direction every cycle. Therefore, for AC electromagnetic pumps, there is no concept of positive and negative poles.
However, it should be noted that when connecting the AC solenoid pump, you must ensure that the power supply is connected to the pump correctly. If the power supply is connected to the pump incorrectly, the pump may not work properly or malfunction.
In addition, some AC solenoid pumps may have different pin definitions, which requires referring to the pump's technical specifications or manufacturer's documentation to determine the correct connection method.
In summary, AC solenoid pumps generally do not have polarity, but they need to be connected correctly to make them work properly.
