CNI developed Rainbow series Multi-channel spectrometer with the features of wide spectral range and high resolution. With synchronous delay device to ensure synchronous acquisition between channels, the high resolution up to 0.1nm. It is suitable for high resolution detection in wide spectal range. CNI can also customize the different channels of the spectrometers according to different customers’ demands. CNI also offers DPSS laser, diode laser, pulsed laser, Raman probe, laser power meter , software analysis and other products, also provides customized products according to customers’ demands.
|
11Features
|
11Applications11111111111111111111111111
|
Spectifications
| 2 Channels (Spectral range 250-650nm) | |||||
| Wavelength range | 250-450nm | 450-650nm | |||
| Resolution (nm) | 0.16 | 0.18 | |||
| 3 Channels (Spectral range 250-645nm) | |||||
| Wavelength range | 250-340nm | 340-420nm | 420-645nm | ||
| Resolution (nm) | 0.12 | 0.1 | 0.18 | ||
| 4 channels (Spectral range 250-1050nm) | |||||
| Wavelength range | 250-450nm | 450-650nm | 650-850nm | 850-1050nm | |
| Resolution (nm) | 0.16 | 0.18 | 0.2 | 0.2 | |
| 5 Channels (Spectral range 249-443nm) | |||||
| Wavelength range | 249-284nm | 284-333nm | 333-364nm | 364-404nm | 404-443nm |
| Resolution (nm) | 0.05 | 0.05 | 0.08 | 0.08 | 0.08 |
|
Spectrometer |
|
|
Wavelength range |
200-1100nm (Wavelength range and resolution can be customized) |
|
Optical resolution |
<0.75nm FWHM |
|
Pixels |
3648 pixels |
|
Pixel size |
8um*200um |
| Signal-to-noise ratio | 300:1 |
| Integration time | 4ms-10s |
| Power consumption | 450mA@5VDC |
|
Delay device |
|
|
Synchronous channel |
6 channels (Other channel quantity optional depending on the spectrometer) |
| Tigger mode | Internal/ external control |
| Delay jitter | <1ns |
| Delay control range | 0-1ms |
| Signal outputs | 5V TTL signal |
|
Software |
|
|
Spectral analysis |
Spectral Analysis and LIBS software |
|
Operating system |
Windows XP/Win7 (32-bit and 64-bit) |
Characteristic
