Transon this 1325 4.5KW 3D CNC Router for wood furniture is a entry level CNC router for users with strong welding steel tube frame. With ordinary T-slot aluminum worktable, 4.5KW water cooled spindle, Mach 3 3 axis USB control system, this 1325 CNC router is with the features of low cost and easy operation, it can widely use in wooden industry, furniture industry, technology research, advertising design, arts creation, teaching project, hobby purposes and some others.
Parameters:
Model |
TSW1325B |
X,Y Worksize |
1300x 2500mm |
Z-axis worksize |
200mm |
Control system |
Mach 3-USB, optional DSP |
Spindle power |
4.5KW water cooling (0-24000rpm) optional |
Motor |
Stepper |
Rail type |
Linear rails |
Transmit |
XY gear rack and Z ballscrew |
Working Speed |
0-15000mm/min |
Command code |
HPGL, G code |
Working precision |
0.05mm |
Power |
AC220V±10% / 50~60Hz380v/50-60hz |
Compatible Software |
Type3/Artcam/UG/Pro-E/Mastercam/Ucancam V9 etc |
Machine size |
3.05m*2m*1.62m |
Package size |
3.16m*2.13m*1.86m |
Weight |
N.W.:1300kg G.W.:1500kg |
Optional Parts |
1.Change control system, 2. Vacuum worktable 3.Rotary Clamp 4.spindle power,5.Water tank(for metal and stone ), 6.Change to Cloose loop stepper motor or Japan Servo Motor |
1, 4.5KW water cooling spindle, 0-24000rpm,
2, T-slot aluminum worktable, use benting kit fix material.
3, Mach 3 USB 3 axis control system, easy operate.
4, YAKO brand motor and driver, can run with smaller noise, lower heating, smoother movement and have better performances at higher speed.
APPLICATION
