Drum Filter Screen （Internal Feed）
Products Description
Drum Filter(Internal Feed)，which is also called drum screen，is suitable for the solid-liquid separation of industrial wastewater and domestic sewage. It can remove the waste solid whose size is more than 0.2mm.The effluent enters the inside of rotary drum through the feed inlet and then passing over the distribution weir on to the drum surface.The particles and water separate as the drum rotates with the solids staying on the screen and passing down the space of the drum .
Technical parameters
|
Model |
Screen Size |
Power |
Material |
Removal rate |
Dimension(mm) |
|
|
|
|
|
|
Solid size |
Solid size |
|
|
HLWLN-300 |
φ300*800mm
Space:0.15-5mm
|
0.55KW |
SS304 |
95% |
55% |
1500*500*1200mm |
|
HLWLN-400 |
φ400*800mm
Space:0.15-5mm
|
|
|
|
|
1800*600*1300mm |
|
HLWLN-500 |
φ500*800mm
Space:0.15-5mm
|
|
|
|
|
1800*700*1300mm |
|
HLWLN-600 |
φ600*800mm
Space:0.15-5mm
|
|
|
|
|
2400*700*1400mm |
|
HLWLN-700 |
φ700*800mm
Space:0.15-5mm
|
|
|
|
|
2700*900*1500mm |
|
HLWLN-800 |
φ800*800mm
Space:0.15-5mm
|
|
|
|
|
2800*1000*1500mm |
|
HLWLN-900 |
φ900*800mm
Space:0.15-5mm
|
|
|
|
3000*1100*1600mm |
|
|
HLWLN-1000 |
φ1000*800mm
Space:0.15-5mm
|
|
|
|
3200*1200*1600mm |
|
Features
1. Simple structure, high reliability;
2.Compact structure, small covering area;
3.The surface of the drum is made of wedge grid, and has excellent hydraulic characteristics.
Application
