Chinese Herb Medicine Powder Fluid Bed Dryer
Main Features:
1. Turn to the Ex-type of Pine Pollen Powder Dryer , we set the explosion release vent on the machine .once the explosion happened , the machine will release the explosion to outside automatically and safely ,
2.Thenardite Powder Dryer have not dead corner .
3.For the loading material of Red Ginseng Powder Dryer, we have choices on vacuum feeding , lifting feeding ,negative feeding and manual feeding for customer .
4. This machine adopts PLC automatic control, all the operation according to the requirements of the user to set the process parameters automatically, can print all the process parameters, the original record is true and reliable. In full compliance with the GMP requirement of pharmaceutical production.
5.The loading and unloading are quick, light and clean, meet the requirements of GMP.
6. For the bag filter , we choose anti-static filtering cloth . Adopting double chamber filtering bags system, remove dust completely.
7. For the machine ,we have CIP and WIP for customer to choose .
8. Adopting multi-fluid nozzle, it guarantees that the formed granule is uniform and the content of powder is very low.
Chinese Herb Medicine Powder Fluid Bed drying machine Characteristics
☆ Fluid bed to achieve fast heat transmission of medium
☆ Seal negative pressure operation, there is no dust
☆ Because of using anti-static material as filter, it is safe in operation
☆ The equipment has no dead corner so it is easy to clean fully and there is no cross pollution
Chinese Herb Medicine Powder Fluid Bed drying machine Applications
Medicine Powder Drying Machine is main used for drying powder or granules from pharmaceutical, foodstuff, chemical and other industries.
Erbang ensures you to the best quality services at all times. Shall you need any further information, please do not hesitate to contact undersigned.
|
Item |
Unit |
3 |
5 |
30 |
60 |
120 |
200 |
300 |
500 |
|
|
Container of raw material |
diameter |
Mm |
300 |
400 |
700 |
950 |
1200 |
1400 |
1600 |
1800 |
|
volume |
L |
12 |
22 |
100 |
220 |
420 |
670 |
1000 |
1500 |
|
|
capacity |
min |
Kg/batch |
1.5 |
4 |
15 |
30 |
80 |
100 |
150 |
250 |
|
max |
Kg/batch |
4 |
6 |
36 |
72 |
140 |
240 |
360 |
600 |
|
|
fan |
power |
Kw |
2.2 |
4 |
5.5 |
11 |
18.5 |
22 |
30 |
45 |
|
Steam consumption |
Kg/batch |
12 |
23 |
70 |
140 |
211 |
282 |
366 |
465 |
|
|
Compressed air |
M3/min |
0.3 |
0.3 |
0.3 |
0.6 |
0.6 |
0.9 |
1.1 |
1.6 |
|
|
Temperature |
℃ |
Room temperature to 120℃ |
|
|||||||
|
Collect rate |
% |
≥99 |
|
|||||||
|
Content of final moisture |
% |
≈0.2 |
|
|||||||
|
Noise |
dB |
≤75dB(A) (main machine is separated from fan) |
|
|||||||
|
Height of main machine |
Mm |
2200 |
2400 |
2800 |
3000 |
3300 |
3800 |
4000 |
4600 |
|
