Shipbuilding plates is a hot rolled steel plate which is used for manufacturing hull structure. It is classified as general strength and high strength hull structural steel, according to minimum yield strength.
Shipbuilding steel plate is a carbon and alloy steel which is compatible with high strength, high heat input soldering and low temperature.
Product Description
|
Type
|
Hot rolled steel plate/Mild plate steel plate /black steel plate/carbon steel plate /sheet plate
|
|
Standard
|
ASTM A20/A20M,ASTM A36,JIS G3115,DIN 17100,EN 10028
|
|
Material
|
Q195,Q235,Q235A, Q235B, Q345B, SPHC, SPHD, SS400,ASTM A36, S235JR, S275JR, S345JR, S355JOH, S355J2H, ASTM A283, ST37, ST52,ASTM A252 Gr. 2(3), ASTM A572 Gr. 500, ASTM A500 Gr. A(B, C, D) and so on
|
|
Length
|
1000~12000mm(normal size 6000mm, 12000mm)
|
|
Width
|
600~3000mm (normal size 1250mm, 1500mm, 1800mm, 2200mm, 2400mm, 2500mm)
|
|
Thickness
|
1.0~100mm
|
| Grade |
Thickness (mm) |
Yieldpoint (Mpa) ≥ |
Tensile Strength (Mpa) |
Elongation （%）≥ |
V-impact test | cold bend test | |||
|---|---|---|---|---|---|---|---|---|---|
|
Temperature （℃） |
Average AKV A kv /J |
b=2a 180° |
b=5a 120° |
||||||
| lengthways | crosswise | ||||||||
| ≥ | |||||||||
| A | ≤50 | 235 | 400~490 | 22 | — | — | — | d=2a | — |
| B | 0 | 27 | 20 | — | d=3a | ||||
| D | -10 | ||||||||
| E | -40 | ||||||||
| A32 | ≤50 | 315 | 440~590 | 22 | 0 | 31 | 22 | — | d=3a |
| D32 | -20 | ||||||||
| E32 | -40 | ||||||||
| A36 | ≤50 | 355 | 490~620 | 21 | 0 | 34 | 24 | — | d=3a |
| D36 | -20 | ||||||||
| E36 | -40 | ||||||||
| variety | Thickness (mm) | Width (mm) | Longth/ inner diameter (mm) | |
|---|---|---|---|---|
| Shipbuilidng plate | cutting edges | 6~50 | 1500~3000 | 3000~15000 |
| non- cutting edges | 1300~3000 | |||
| Shipbuilidng coil | cutting edges | 6~20 | 1500~2000 | 760+20~760-70 |
| non-cutting edges | 1510~2010 | |||
| Thickness (mm) | theoretical weight | Thickness (mm) | theoretical weight | ||
|---|---|---|---|---|---|
| Kg/ft2 | Kg/m2 | Kg/ ft2 | Kg/m2 | ||
| 6 | 4.376 | 47.10 | 25 | 18.962 | 196.25 |
| 7 | 5.105 | 54.95 | 26 | 20.420 | 204.10 |
| 8 | 5.834 | 62.80 | 28 | 21.879 | 219.80 |
| 10 | 7.293 | 78.50 | 30 | 23.337 | 235.50 |
| 11 | 8.751 | 86.35 | 32 | 25.525 | 251.20 |
| 12 | 10.21 | 94.20 | 34 | 26.254 | 266.90 |
| 14 | 10.939 | 109.90 | 35 | 27.713 | 274.75 |
| 16 | 11.669 | 125.60 | 40 | 29.172 | 314.00 |
| 18 | 13.127 | 141.30 | 45 | 32.818 | 353.25 |
| 20 | 14.586 | 157.00 | 48 | 35.006 | 376.80 |
| 22 | 16.044 | 172.70 | 50 | 36.464 | 392.50 |
| 24 | 18.232 | 188.40 | |||
