Main application
The pharmaceutical ribbon blending machine is composed of U or cylindrical barrel body, frame, transmission motor, stirring tool shaft and electric control box. Double-layer spiral blades are arranged on the driving spindle. The external blades transport materials to the middle and the internal blades transport materials to the outside. Under the convective movement of the double-layer helical belt, a mixed environment with low power and high efficiency is formed. The inner and outer diameter spiral mounted on the stirring shaft drives the materials in the barrel body, so that the agitator in the barrel body to the material turning process. This is a spices powder mixer machine and a food grade powder mixing machine.
There are 50-20000L capacity specifications for customers to choose from. The inside of the barrel body is polished smooth, and the blade is stirred without dead Angle. It can be mixed evenly in 5-10 minutes per batch. All stainless steel center shaft and single or double "S" shaped paddle, mix fast, uniform. In addition, our company has screw feeding machine, vacuum suction machine, conveyor belt and other supporting, minus the feeding platform, reduce labor intensity, save time and labor.
Technical data
|
Model
|
Total volume (m3)
|
Loading coefficient
|
Power(kw)
|
Overall size(mm)
|
Weight(kg)
|
|
WLDH-0.1
|
0.1
|
0.4-0.8
|
3
|
1190*740*770
|
330
|
|
WLDH-0.2
|
0.2
|
0.4-0.8
|
3
|
1550*700*800
|
420
|
|
WLDH-0.3
|
0.3
|
0.4-0.8
|
4
|
2030*630*980
|
720
|
|
WLDH-0.5
|
0.5
|
0.4-0.8
|
7.5
|
2320*730*1130
|
980
|
|
WLDH-1
|
1
|
0.4-0.8
|
11
|
2800*920*1320
|
1700
|
|
WLDH-1.5
|
1.5
|
0.4-0.8
|
11
|
3180*1020*1550
|
1800
|
|
WLDH-2
|
2
|
0.4-0.8
|
15
|
3310*1120*1640
|
2100
|
|
WLDH-3
|
3
|
0.4-0.8
|
18.5
|
3750*1290*1820
|
3000
|
|
WLDH-4
|
4
|
0.4-0.8
|
22
|
4220*1400*1990
|
3980
|
|
WLDH-5
|
5
|
0.4-0.8
|
22
|
4220*1500*2100
|
4620
|
|
WLDH-6
|
6
|
0.4-0.8
|
30
|
4700*1610*2260
|
6180
|
|
WLDH-8
|
8
|
0.4-0.8
|
37
|
4420*2150*2470
|
8200
|
|
WLDH-10
|
10
|
0.4-0.8
|
45
|
5520*2960*2720
|
8920
|
|
WLDH-12
|
12
|
0.4-0.8
|
45
|
5720*3010*2840
|
9520
|
|
WLDH-15
|
15
|
0.4-0.8
|
55
|
5840*3540*2940
|
9950
|
If you are interested in the product, contact 2bvideo.com for more information for more information
