Foodstuff Industry Flavours Powder Mixing Machine
Flavours Powder Mixing Equipment Working principle:
Driven by the driving shaft, the barrel with the materials loaded performs cycling compound movements of translation and tumbling, which make the materials move annularly, radially and axially the body, thus achieving mutual flow, spread, accumulation and mixing of materials for the purpose of fully mixing effect.
Foodstuff Industry Flavours Powder Mixing Machine Characteristics:
1. Flavours Powder Mixer possesses high mixing uniformity,it can reach 99.9%
2. Flavours Powder Mixer Machine reach food grade because the machine made by all stainless steel-304 stainless steel or 316L stainless steel.
3. The process of manufacturing Flavours Powder Mixing Machine has achieved GMP.
4. Flavours Powder Blender has been approved CE.
Flavours Powder Blending Machine Application and Features:
1.The Flavours Powder Mixing Machinery are suitable for mixing powder and granulate materials in pharmaceutical, chemical, food stuff, light industry, electronic, machinery, mining, metallurgical and national defense industrial, featuring high evenness mixing.
2. Mixing barrel moves in multiple directions, there is no centrifugal force on the material, as well as no phenomena of gravity segregation, delaminating and accumulation of materials so that the mixing rate can be up to 99.9 percent for the materials with big difference in terms of specific gravity. Therefore, this salt mixing machine is an ideal product current compare with other various mixers.
3. High loading rare (max. loading 80 percent).
|
Model |
barrel capacity(L) |
max loading capacity(L) |
max loading weight(Kg) |
speed of driving shaft(r/min) |
motor power(kw) |
overall dimensions(mm) |
total weight |
|
SYH-1 |
1 |
0.8 |
0.4 |
15-30 |
0.12 |
500x600x600 |
50 |
|
SYH-5 |
5 |
4 |
2 |
15-30 |
0.25 |
600x1000x1000 |
150 |
|
SYH-15 |
15 |
12 |
6 |
8-15 |
0.37 |
700x1000x700 |
200 |
|
SYH-50 |
50 |
40 |
20 |
8-15 |
1.1 |
1000x1400x1200 |
300 |
|
SYH-100 |
100 |
80 |
40 |
8-15 |
1.5 |
1200x1700x1500 |
500 |
|
SYH-200 |
200 |
160 |
80 |
8-15 |
2.2 |
1400x1800x1600 |
800 |
|
SYH-400 |
400 |
320 |
160 |
8-15 |
4 |
1800x2100x1950 |
1200 |
|
SYH-600 |
600 |
480 |
240 |
8-15 |
5.5 |
1900x2100x2250 |
1500 |
|
SYH-800 |
800 |
640 |
320 |
8-15 |
7.5 |
2600X2380X2500 |
2000 |
If you are interested in the product, contact 2bvideo.com for more information for more information
